Studying spin system dynamics concerns different rapidly growing fields of technology such as developing new types of information transfer systems [1], quantum computing [2, 3], new approaches for magnetic recording and reading [4]. The most common way to excite spin oscillations is by using the inverse Faraday effect (IFE). It is based on a Raman-like coherent optical scattering process and does not require absorption of light. This gives us two main advantages of this effect: it is instantaneous and non-thermal [5]. IFE results in magnetization induced by high-power laser radiation according to the following formula:&lt;br/&gt;&lt;i&gt;M&lt;/i&gt;&lt;sub&gt;in&lt;/sub&gt;=&lt;i&gt;χ&lt;/i&gt;/16&lt;i&gt;π&lt;/i&gt; [&lt;i&gt;E&lt;/i&gt;×&lt;i&gt;E&lt;/i&gt;*], (1)&lt;br/&gt;where &lt;i&gt;χ&lt;/i&gt; is magneto-optical susceptibility, &lt;i&gt;E&lt;/i&gt; is the electric field of the incident light, and &lt;i&gt;E&lt;/i&gt;* is its complex conjugate. The cross product in formula (1) is zero for linearly polarized incident light and is maximum for circularly polarized light.&lt;br/&gt;The excitation of high order spin waves requires the nonuniform distribution of the electromagnetic field in the medium. It is commonly achieved by using the nanostructured materials in which the resonant phenomena can occur breaking the uniformity of the field. For example, in work [6] the all-dielectric 1D grating was used to generate spin waves due to the excitation of propagating waveguide modes.&lt;br/&gt;Another way to excite spin waves is the utilization of anisotropic materials in which the polarization conversion of the incident light occurs. Such a transformation leads to the spatial dependency of magnetization induced via IFE. This nonuniformity of the magnetic torque allows one to excite the spin waves of a high order.&lt;br/&gt;Let us consider the case of biaxial crystals the influence on the incident light polarization of which is described by the permittivity tensor ε&lt;sub&gt;ij&lt;/sub&gt;. The diagonal components of this tensor are assumed not to be equal &lt;i&gt;ε&lt;/i&gt;&lt;sub&gt;11&lt;/sub&gt;≠&lt;i&gt;ε&lt;/i&gt;&lt;sub&gt;22&lt;/sub&gt;≠&lt;i&gt;ε&lt;/i&gt;&lt;sub&gt;33&lt;/sub&gt; and connected with cartesian coordinates &lt;i&gt;x&lt;/i&gt;, &lt;i&gt;y&lt;/i&gt;, and &lt;i&gt;z&lt;/i&gt; respectively. Let the light fall under the normal incidence to the plane of the material and propagate along the &lt;i&gt;z&lt;/i&gt;-axis. Placing the material under study in an external magnetic field along the &lt;i&gt;z&lt;/i&gt;-axis leads to the appearance of additional off-diagonal components which are &lt;i&gt;ε&lt;/i&gt;&lt;sub&gt;12&lt;/sub&gt;=-&lt;i&gt;i&lt;/i&gt;×&lt;i&gt;g&lt;/i&gt; and &lt;i&gt;ε&lt;/i&gt;&lt;sub&gt;21&lt;/sub&gt;=&lt;i&gt;i&lt;/i&gt;×&lt;i&gt;g&lt;/i&gt;. Polarization of the light propagating in such a medium transforms due to the anisotropy and Faraday effect. This process is described theoretically in [7].&lt;br/&gt;To be more specific, consider the YFeO&lt;sub&gt;3&lt;/sub&gt; crystal with an orthorhombic cell. Its crystallographic axes &lt;i&gt;a&lt;/i&gt;, &lt;i&gt;b&lt;/i&gt;, and &lt;i&gt;c&lt;/i&gt; are oriented along &lt;i&gt;x&lt;/i&gt;, &lt;i&gt;y&lt;/i&gt;, and &lt;i&gt;z&lt;/i&gt; axes respectively. The main refractive indices of such material are n&lt;sub&gt;1&lt;/sub&gt;=2.365, n&lt;sub&gt;2&lt;/sub&gt;=2.4, n&lt;sub&gt;3&lt;/sub&gt;=2.337 at the wavelength of 633 nm (&lt;i&gt;ε&lt;/i&gt;&#39;&#39; is assumed to be zero). The transformation of the incident light with circular polarization when it passes through anisotropic medium results in oscillations of the magnetization induced via IFE (blue line on Fig. 1). It worth noting that oscillations of magnetization occur for linearly polarized light. The maximum value of cross-product in formula (1) can be achieved for the polarization of incident light at an angle of 45° to the &lt;i&gt;a&lt;/i&gt; crystal axis (green line on Fig. 1). In this case, the material behaves as a quarter-wave plate fully transforming the initial linear polarization to circular. One can observe the oscillations even for light polarized linearly along the crystal axis but their maximum value is two times smaller compared to the previous scenarios (Fig. 2). In this situation, the polarization transformation due to birefringence must disappear but the Faraday effect slightly rotates the polarization off the axis allowing the anisotropy to take its place.&lt;br/&gt;The oscillations of IFE due to the birefringent properties of the material under study have been theoretically demonstrated. Such a behavior of the induced magnetization is important for generating spin waves of a high order allowing one to avoid additional nanostructuring of the material.&lt;br/&gt;This work was supported by the Ministry of Science and Higher Education of the Russian Federation (mega-grant no. 075-15-2019-1934).

**References:**

[1] S. Neusser and D. Grundler, Advanced Materials, Vol. 21 p. 2927 (2009)&lt;br/&gt;[2] K. Ganzhorn, S. Klingler, T. Wimmer, et al, Applied Physics Letters, Vol. 109, p. 022405 (2016)&lt;br/&gt;[3] D. Lachance-Quirion, Y. Tabuchi, A. Gloppe, et al, Applied Physics Express, Vol. 12, p. 070101 (2019)&lt;br/&gt;[4] D.O. Ignatyeva, C.S. Davies, D.A. Sylgachev, et al, Nature Communications, Vol. 10, p. 1 (2019)&lt;br/&gt;[5] A.V. Kimel, A. Kirilyuk, P.A. Usachev, et al, Nature, Vol. 435, p. 655 (2005)&lt;br/&gt;[6] A.I. Chernov, M.A. Kozhaev, D.O. Ignatyeva, et al, Nano Letters, Vol. 20, p. 5259 (2020)&lt;br/&gt;[7] A.K. Zvezdin, V.A. Kotov, Modern magnetooptics and magnetooptical materials, CRC Press (1997)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/9fd7730e609d00e4f4b1fe8becda2c13.jpg)
Fig. 1. Cross product of electric field and its complex conjugate depending on the propagation length for circularly (blue line) and linearly polarized at an angle of 45° to the crystal axis (green line) incident light.

![](https://assets.underline.io/uploads/markdown_image/1/image/a63c9245721032602764f78c072ba99b.jpg)
Fig. 2. Cross product of electric field and its complex conjugate depending on the propagation length for incident light polarized along the &lt;i&gt;a &lt;/i&gt;crystal axis.

INTERMAG 2021

 Oscillating Behavior of Inverse Faraday Effect in YFeO3

INTERMAG 2021 Welcome Video




<figure class="video_container">
 <iframe src="https://screencast-o-matic.com/player/crflqFVnUpZ?v=6&ff=1&title=0&controls=1" width=640 height=360 frameborder="0" allowfullscreen="true"> </iframe>
</figure>

Want to buy a ticket?

Register for INTERMAG 2021 here

[![](https://assets.underline.io/uploads/markdown_image/1/image/17ce76e7960db633258024eef8d6da7f.png)](https://intermag.org/register)

Got your ticket, but still can’t access the event?

Contact us and our team will look into it.

Studying spin system dynamics concerns different rapidly growing fields of technology such as developing new types of information transfer systems [1], quantum computing [2, 3], new approaches for magnetic recording and reading [4]. The most common way to excite spin oscillations is by using the inverse Faraday effect (IFE). It is based on a Raman-like coherent optical scattering process and does not require absorption of light. This gives us two main advantages of this effect: it is instantaneous and non-thermal [5]. IFE results in magnetization induced by high-power laser radiation according to the following formula: Min=χ/16π [E×E*], (1) where χ is magneto-optical susceptibility, E is the electric field of the incident light, and E* is its complex conjugate. The cross product in formula (1) is zero for linearly polarized incident light and is maximum for circularly polarized light. The excitation of high order spin waves requires the nonuniform distribution of the electromagnetic field in the medium. It is commonly achieved by using the nanostructured materials in which the resonant phenomena can occur breaking the uniformity of the field. For example, in work [6] the all-dielectric 1D grating was used to generate spin waves due to the excitation of propagating waveguide modes. Another way to excite spin waves is the utilization of anisotropic materials in which the polarization conversion of the incident light occurs. Such a transformation leads to the spatial dependency of magnetization induced via IFE. This nonuniformity of the magnetic torque allows one to excite the spin waves of a high order. Let us consider the case of biaxial crystals the influence on the incident light polarization of which is described by the permittivity tensor εij. The diagonal components of this tensor are assumed not to be equal ε11≠ε22≠ε33 and connected with cartesian coordinates x, y, and z respectively. Let the light fall under the normal incidence to the plane of the material and propagate along the z-axis. Placing the material under study in an external magnetic field along the z-axis leads to the appearance of additional off-diagonal components which are ε12=-i×g and ε21=i×g. Polarization of the light propagating in such a medium transforms due to the anisotropy and Faraday effect. This process is described theoretically in [7]. To be more specific, consider the YFeO3 crystal with an orthorhombic cell. Its crystallographic axes a, b, and c are oriented along x, y, and z axes respectively. The main refractive indices of such material are n1=2.365, n2=2.4, n3=2.337 at the wavelength of 633 nm (ε'' is assumed to be zero). The transformation of the incident light with circular polarization when it passes through anisotropic medium results in oscillations of the magnetization induced via IFE (blue line on Fig. 1). It worth noting that oscillations of magnetization occur for linearly polarized light. The maximum value of cross-product in formula (1) can be achieved for the polarization of incident light at an angle of 45° to the a crystal axis (green line on Fig. 1). In this case, the material behaves as a quarter-wave plate fully transforming the initial linear polarization to circular. One can observe the oscillations even for light polarized linearly along the crystal axis but their maximum value is two times smaller compared to the previous scenarios (Fig. 2). In this situation, the polarization transformation due to birefringence must disappear but the Faraday effect slightly rotates the polarization off the axis allowing the anisotropy to take its place. The oscillations of IFE due to the birefringent properties of the material under study have been theoretically demonstrated. Such a behavior of the induced magnetization is important for generating spin waves of a high order allowing one to avoid additional nanostructuring of the material. This work was supported by the Ministry of Science and Higher Education of the Russian Federation (mega-grant no. 075-15-2019-1934).

**References:**

[1] S. Neusser and D. Grundler, Advanced Materials, Vol. 21 p. 2927 (2009) [2] K. Ganzhorn, S. Klingler, T. Wimmer, et al, Applied Physics Letters, Vol. 109, p. 022405 (2016) [3] D. Lachance-Quirion, Y. Tabuchi, A. Gloppe, et al, Applied Physics Express, Vol. 12, p. 070101 (2019) [4] D.O. Ignatyeva, C.S. Davies, D.A. Sylgachev, et al, Nature Communications, Vol. 10, p. 1 (2019) [5] A.V. Kimel, A. Kirilyuk, P.A. Usachev, et al, Nature, Vol. 435, p. 655 (2005) [6] A.I. Chernov, M.A. Kozhaev, D.O. Ignatyeva, et al, Nano Letters, Vol. 20, p. 5259 (2020) [7] A.K. Zvezdin, V.A. Kotov, Modern magnetooptics and magnetooptical materials, CRC Press (1997)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/9fd7730e609d00e4f4b1fe8becda2c13.jpg)
Fig. 1. Cross product of electric field and its complex conjugate depending on the propagation length for circularly (blue line) and linearly polarized at an angle of 45° to the crystal axis (green line) incident light.

![](https://assets.underline.io/uploads/markdown_image/1/image/a63c9245721032602764f78c072ba99b.jpg)
Fig. 2. Cross product of electric field and its complex conjugate depending on the propagation length for incident light polarized along the a crystal axis.

technical paper

The significance of phase noise lies in the fact that most if not all devices based on magnons employ the nonlinearity of the magnetic system in order to realize their functionalities. An important entity in such parametrically excited systems is the phase of the magnons, which plays a crucial role in governing the nonlinear physics and hence the physical properties of interest of such devices. It is due to this importance of phase that in the recent past, many devices have been proposed and/or demonstrated that directly employ the magnon phase for the realization of important applications. The analytical theory developed is supported using rigorous GPU-based micromagnetic simulations [1]. A 5.1 μm thick sample of yttrium iron garnet (YIG) with saturation magnetization, 145 emu/cm3 , and exchange constant, 3.77 x 10-7 erg/cm is used. Demagnetization-, exchange-, and thermal-fields are included in addition to the applied-fields. A primary microwave signal of 6 GHz is used at a bias-field of .200 Oe. In our previous study [2], we had provided an accurate theoretical prediction of the increase in the threshold-field when an additional secondary signal is introduced. The secondary signal modifies the phase-relationship between the magnons and the primary microwave signal. While the importance of the phase as a fundamental entity has increased, studies on the implications of the phase-noise are few. This is due primarily to the difficulties in accessing, manipulating, and analyzing the phase accurately. Previous studies of noise mainly consider thermal-noise and often make use of the macrospin approximation. In magnonics, noise studies exist largely only for spin-torque oscillators. In the radio frequency (RF) applications, noise is usually modeled at a circuit level [3], and a microscopic study of phase-noise remains to be done. Ours is a more general treatment of phase-noise implications and, consequently, applicable across all magnon-based nonlinear applications. We have used analytical techniques drawn from hydrodynamics to evaluate the effects of phase-noise. Moreover, the simulations performed are based on state-of-art GPUs, using software optimized to study the magnon based physics specifically. Such simulations would not have been computationally possible in the past. Hence, this is a timely study of an important entity. (1) At first, we introduce a Gaussian phase-noise of zero mean and standard-deviation,σ , to understand its impact on the nonlinearity threshold. For a temporal-noise, we find that the threshold-field scales as e(σ^2)/2, but the growth rate of the magnons that partly determines the transient-time scales as e-(σ^2)/2 (Fig. 1). We have demonstrated these results analytically as well as using micromagnetic simulations. The results are of particular importance for RF devices like Frequency Selective Limiters (FSLs), Signal to Noise-ratio Enhancers, etc., that are often employed in noisy environments and are therefore subjected to temporal phase-noise. As mentioned earlier, few studies of phase-noise at the magnonic scale exists for such conventional RF devices despite the nonlinear behavior being a crucial part of device-functionality. (2) We find that similar changes as above are seen in the threshold-field and the growth-rate when a spatial phase-noise of similar mean and standard-deviation is employed. As can be observed from Fig. 2, the simulation data-points are nearly identical to those obtained in the case of temporal noise. For magnonic applications [4], this points to the importance of process variations and microstructural quality during the production of magnetic samples that can give rise to spatial-noise conditions. (3) Compared with phase-noise, we find that frequency-noise leads to only trivial variations in the threshold-field. Frequency noise alters the amplitude of the spin-waves. Therefore, information when encoded into the spin-wave amplitude, is more likely to suffer distortion under frequency noise when compared with phase noise. Apart from lowering the signal to noise ratio, frequency noise increases the magnon frequency deviation. Some of the proposed magnonic logic schemes [5] employ a combination of amplitude-, phase- and frequency- encoding to realize beyond-Neumann architectures where the above considerations would be crucial. Likewise, these results also play an important role in conventional communication systems that employ a combination of modulation techniques. Our studies, thus, allow phase noise considerations to be included in the design and/or operation of nonlinear magnetic devices. These results are important for both the traditional and novel magnon-based applications since device performance characteristics often strongly depend on the threshold-field as well as the transient-time. This is evident, e.g., in the ongoing efforts to miniaturize nonlinear magnetic rf device -FSL- especially for autonomous automobile applications [6]. Also, our results are independent of the mode of pumping (parallel or perpendicular) and the magnetic-material (applies to insulators, e.g., YIG as well as metals, e.g., NiFe). The results, in general, could be used to understand the nonlinear properties of other parametric systems that involve three-particle processes.

**References:**

1. A. Venugopal, T. Qu, and R. H. Victora, IEEE Trans. Microwave Theory Tech., vol. 68, no. 2, pp. 602–610 (2020). 2. A. Venugopal, T. Qu, and R. H. Victora, Appl. Phys. Lett., vol. 117, no. 152404 (2020). 3. M. Shukla, M. Y. Koledintseva, M. Geiler, et al, "Adaptive Interference Mitigation Using Frequency-Selective Limiters over GPS Band for Automotive Applications," 2020 IEEE International Symposium on Electromagnetic Compatibility & Signal/Power Integrity (EMCSI), Reno, NV, USA, pp. 614-618 (2020). 4. A. A. Serga, A. V. Chumak and B. Hillebrands, J. Phys. D: Appl. Phys. vol. 43, no. 264002, (2010). 5. A. Khitun, M. Bao and K. L. Wang, J. Phys. D: Appl. Phys., vol. 43, no. 264005 (10pp), (2010). 6. A. O. Boryssenko, S. M. Gillette, M. Y. Koledintseva, IEEE Trans. Microwave Theory Tech., vol. 67, no. 12, pp. 4871-4880 (2019).

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/874dd0937c495ae22693803fdb8ffab9.jpg)
Fig. 1. Comparison of simulated data and theoretical prediction of threshold-fields and the slope of growth rate w.r.t microwave field intensity.

![](https://assets.underline.io/uploads/markdown_image/1/image/af9ea0e88443cf351b0e314bebde8f05.jpg)
Fig. 2. Growth rate of magnons vs the primary rf field intensity for various phase-noise standard deviations. ‘T’ refers to temporal noise, ‘S’ to spatial noise.

 Phase Noise Considerations in Magnon based Parametric Excitations

We investigate the role of disorder on the various topological magnonic phases present in deformed honeycomb ferromagnets. To this end, we introduce a bosonic Bott index to characterize the topology of magnon spectra in finite, disordered systems. The consistency between the Bott index and Chern number is numerically established in the clean limit. We demonstrate that topologically protected magnon edge states are robust to moderate disorder and, as anticipated, localized in the strong regime. We predict a disorder-driven topological phase transition, a magnonic analog of the “topological Anderson insulator” in electronic systems, where the disorder is responsible for the emergence of the nontrivial topology. Combining the results for the Bott index and transport properties, we show that bulk-boundary correspondence holds for disordered topological magnons. Our results open the door for research on topological magnonics as well as other bosonic excitations in finite and disordered systems [1]. We start from a ferromagnetic honeycomb layer [Fig. 1(a), (c)]. The honeycombs can be distorted, controlled by the bond angle θ, as shown in Fig. 1. We consider nearest-neighbor (NN) ferromagnetic exchange energy, NN pseudodipolar interaction [2], and on-site anisotropy energy. For strong enough perpendicular easy-axis anisotropy, the out-of-plane ferromagnetic state is an equilibrium state. We then calculate the spin wave spectra upon this state using the standard methods. Because of the bosonic commutation relation, we result in a non-Hermitian generalized eigenvalue problem η H T=Tη E, where H is the Hermitian Hamiltonian, E is the diagonal matrix of eigenvalues, η is a metric due to the bosonic commutation relation, and T is the Bogoljiubov transformation matrix diagonalizing the Hamiltonian. We define a bosonic Bott index, which takes the same form as the electronic Bott index [3] but with a modified projector P=TηΓT† η, where Γ is a matrix electing certain states. We first consider the clean limit. Figure 1(b) and (d) show spin wave spectra for infinite system, 100-wide zigzag strip, and 40*40 finite flake (from left to right) for normal and squeezed honeycomb lattices, respectively. Gapped bulk spectra in infinite and periodic systems and gapless (crossing) edge states for an open strip can be observed, indicating a nontrivial topology. A topological transition happens at θ=π/2. When θ&gt;π/2 such as Fig. 1(a) (θ=2π/3), the upper (lower) band has Chern number +1 (-1), and the Bott indices for the finite flake give the same values as the Chern numbers. For θ&lt;π/2 such as Fig. 1(c) (θ=5π/12), the signs of Chern numbers as well as Bott indices flip. The system can also be tuned to be topologically trivial by staggered anisotropy. The Bott indices are still consistent with Chern numbers during this process. Then we add a non-correlated random anisotropy ranged [-W,W] onto each spin in the normal honeycomb lattice to study the effect of disorder. In this non-periodic system, the k-space Chern number cannot be directly used, and the Bott index becomes powerful. When the system is nontrivial in clean limit (Bott index is 1 for the upper band), for moderate disorder, the Bott index is still one, meaning that the system keeps nontrivial. When the disorder is strong enough, a topological transition occurs and the system becomes topologically trivial [Fig. 2(a)]. This phenomenon is consistent with the common wisdom that the topology is quite robust since very strong disorder is needed to break the topology. A more remarkable phenomenon occurs when the disorder affects a topologically trivial system [Fig. 2(b)]. For a trivial system in clean limit (the band structure of a strip near the gap in the clean limit is shown in the inset), there are no gapless edge states inside the bulk gap. Surprisingly, as the disorder strength increases, the Bott index increases from zero and reaches a plateau of B=1 and then drops to zero large disorder. This finding indicates that there exists a disorder-induced topological phase, similar to the topological Anderson insulator phase in electronic systems [4]. We further demonstrate the bulk-boundary correspondence in our topological magnon model by studying the transport properties. We calculate the total transmission of magnons at the mid-gap energy across a disordered sample sandwiched by two clean leads, and compare them with the Bott index results in Fig. 2(a) and (b). The agreement is quite good, demonstrating the fact that when the Bott index is nontrivial, there exists robust edge channel inside the bulk band gap, which is the common wisdom of bulk-boundary correspondence. The existence of edge states in strongly disordered magnets is further confirmed by the calculation of the real-space wave functions. Eigenstates whose energies are closest to the mid-gap energy for a certain disorder configuration are calculated, and the expectation values 〈Sx〉, 〈Sy〉 are plotted in Fig. 2(c) and (d), corresponding to the circled data points in (a) and (b), respectively.

**References:**

[1] X. S. Wang , A. Brataas, and R. E. Troncoso, Phys. Rev. Lett. 125, 217202 (2020). [2] G. Jackeli and G. Khaliullin, Phys. Rev. Lett. 102, 017205 (2009). [3] H. Huang and F. Liu, Phys. Rev. Lett. 121, 126401 (2018). [4] J. Li, R.-L. Chu, J. K. Jain, and S.-Q. Shen, Phys. Rev. Lett. 102, 136806 (2009).

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/cca9b8afc32254bc08681bd6816a5560.png)
Fig. 1. (a) Schematic of a normal honeycomb magnet. (b) From left to right: the spin-wave spectra for infinite samples , zigzag strips of width 100 along rows, and 40*40 finite samples. (c) Schematic of a squeezed honeycomb magnet of θ=5π/12. (d) Spin-wave spectra for (c).

![](https://assets.underline.io/uploads/markdown_image/1/image/308b334f57cb35f1140a75f4540bcf6a.png)
Fig. 2. Comparison between the Bott index and the total transmission for (a) topologically nontrivial and (b) trivial systems. (c) and (d) plot 〈Sx〉, 〈Sy〉 of eigenstates. The size of the circles indicates the amplitude, and the color encodes the azimuthal angle.

 Bosonic Bott Index and Disorder-Induced Topological Transitions of Magnons

Spin waves (SWs) are precessional magnetization disturbances propagating in magnetic media in the form of waves at microwave frequencies [1] that are the most commonly used frequencies range for wireless communication. Wavelengths of SWs are several orders of magnitude shorter than the lengths of electromagnetic waves of corresponding frequencies. The dynamics of SWs even in uniformly magnetized films is extraordinarily rich. It is easy to obtain effects difficult to be achived for other type of waves, such as nonreciprocity, excitation caustic-beam that are characteristic for hyperbolic media, easy external control over propagation (e.g., by inhomogeneous magnetic field) [2]. Non-linear phenomena are also easily available[1,3]. All these make SWs to be a promising candidate for information carriers, especially in the context of beyond-CMOS applications [4]. SWs may be confined to certain areas of the thin film, e.g., in a potential well created by an inhomogeneity of the static demagnetizing field in the vicinity of film’s edge. Such localized modes are called edge SWs (E-SWs). Usually, the frequencies of E-SWs are downshifted with respect to bulk-type SWs (B-SWs), i.e., SWs propagating far from the edge where the static effective field is practically homogenous. Here, we theoretically study by means of micromagnetic simulations [5] and analytical modelling the dynamics of the E-SWs localized at the edge of thin permalloy film and their interaction with B-SWs. Firstly, we focus on the utilization of the E-SWs to excite short B-SWs propagating in the form of plane waves. Secondly, we study the inelastic non-linear scattering of B-SW beam by the E-SWs. We consider propagation of the E-SW along the edge of 10 nm thick permalloy film that is uniformly magnetized by the external field of value 300 mT directed perpendicularly to the film’s edge (see Fig. 1a, where the system is presented along with exemplary result of a simulation). The E-SW is excited by the point-source-like microwave field of frequency 12 GHz located at the film’s edge. There are visible two prominent peaks in the simulated spectrum (Fig. 1b). The first one corresponds to the frequency of the microwave field (12 GHz) and propagation of the E-SWs, whereas the second peak has doubled frequency (24 GHz) and corresponds to the B-SWs propagating obliquely outwards the edge in the form of plane waves. It indicates excitation of the B-SWs by the propagating E-SWs in the process of second harmonic generation. Noteworthy, the wavelength of the B-SWs is over twice shorter than the wavelength of the E-SWs shown in Fig. 1a. The B-SW of wavelength equal to 78 nm is excited by the 285 nm long E-SW. For the same sample, we analytically and numerically analyze the interaction of an obliquely incident B-SW beam (at frequency f) with an E-SWs at frequency n. We find that due to the inelastic scattering the secondary B-SW beams with up- and down-shifted frequency (f-n, f+n) can be excited. In Fig. 2 an exemplary result of simulation for a B-SW beam incident at the films edge where E-SW propagates and the resulting secondary scattered beam with frequency (f+ν)=42 GHz are shown. Moreover, we observe angular shifts between the primary incident and the scattered beams with shifted frequencies and analyze the efficiency of the scattering process. Finally, we present an application of this effect for SW demultiplexing. Acknowledgments. The research was supported by the National Science Centre of Poland, project no. 2019/35/D/ST3/03729 (P.G. and M.K.); COST action under project CA17123 MAGNETOFON (I.L.); the Spanish MCIU grant PID2019-108075RB-C3-3 (K.G.). K.G. acknowledges support by IKERBASQUE (the Basque Foundation for Science). The simulations were performed at the Poznan Supercomputing and Networking Center (Grant No. 398).

**References:**

 [1] A. Gurevich and G. Melkov, Magnetization oscillations and waves (CRC Press, Boca Raton, 1996). [2] A. Barman et al., J. Appl. Phys. 128, 170901 (2020). [3] A. V. Chumak et al., Nat. Phys. 11, 453 (2015). [4] B. Murmann, B. Hoefflinger, "IRDS—International Roadmap for Devices and Systems, Rebooting Computing, S3S" in NANO-CHIPS 2030 (Springer, Cham, 2020). [5] A. Vansteenkiste et al., AIP Advances 4, 107133 (2014).

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/6f369e1f64f9a7c41706068472bcb0f0.jpg)
Fig. 1. (a) System under consideration with the snapshot of the out-of-plane magnetization component (mz) in the steady state with E-SW excitation at 12 GHz. The source of E-SWs is located in the area indicated by the white triangle. (b) Simulated SW frequency spectrum.

![](https://assets.underline.io/uploads/markdown_image/1/image/3d4019bb873d5286156ad035fb24cd24.jpg)
Fig. 2. Scheme of the system under investigation with the result of micromagnetic simulation performed for B-SW beam at frequency f = 30 GHz incident under the angle 60° and scattered on an E-SW at ν =12 GHz. Red (at the edge), yellow and blue (beams) corresponds to presence of the SWs of frequencies ν, f, and f+ν, respectively. The white color denotes areas, where at least two frequencies are mixed.

 Inelastic scattering of spin wave beam at the edge localized spin waves and second harmonic generation of spin waves

Nowadays a lot of effort is put into the creation of a practical quantum computer. For this ambitious aim different research fields propose and investigate new materials and technologies. One of such promising systems, a magnon Bose-Einstein condensate (BEC)in magnetic crystals, may allow the creation of magnon-BEC-based qubit at room temperature. A prerequisite for such a qubit is the appearance of spontaneous coherence in magnon BEC. Also, the presence of coherence of the magnon Bose-Einstein condensate is essential for understanding such fundamental properties of it as the possibility of a dissipative magnon supercurrent [1], excitation of Josephson oscillations [2], and propagation of Bogoliubov waves [3]. In most of the previous studies in this field, the magnon BEC is investigated by means of Brillouin light scattering (BLS) spectroscopy [4,5] delivering information about the spectral density of a magnon gas. Unfortunately, due to the limited frequency resolution of the optical Fabry-Pérot interferometers used in BLS facilities, the conventional BLS technique does not allow one to prove the coherence of a magnon BEC directly. The insufficient frequency resolution makes it impossible to separate the relaxation dynamics of condensed and thermal magnons. Moreover, the possible outflow of the condensate from a spatially localized probing light spot complicates the interpretation of the obtained experimental results (see [6] and the corresponding discussion in [7]). For all these reasons only indirect indications of the coherency, obtained on the magnon BEC in magnetic crystals, could be provided yet. Up to this day, a decisive proof of the full coherence magnon BEC remained elusive. In our work, we report a first direct experimental observation of the evolution of magnon BEC towards full coherence, whose degree is limited only by the natural processes of the magnon relaxation into the crystal lattice. To achieve this, we use a novel concept that enhances the coupling of the parametrically-driven magnon system with the probing electromagnetic field. The obtained electric signal was investigated time-resolved by a spectrum analyzer to reach the required frequency resolution necessary for the proper display of the magnon BEC state. A pulsed electromagnetic parametric pumping was used to inject magnons, increase, thus the chemical potential of the magnon gas, and trigger the BEC formation process. It is found that the radiation spectrum picked up after the terminization of a pump pulse is narrowed by two orders of magnitude, compared to the broad-band spectrum obtained during the process of parametric pumping. The resulting spectrum width is only limited by the magnon relaxation frequency. We study this spectrum evolution in many details and identify the conditions for BEC creation. We believe that this direct demonstration of the coherence of the magnon BEC brings the implementation of the room temperature BEC-based computing closer. This research was funded by the European Research Council within the Advanced Grant No. 694709 “SuperMagnonics” and by the Deutsche Forschungsgemeinschaft (DFG, German Research Foundation) within the Transregional Collaborative Research Center – TRR 173 – 268565370 “Spin+X” (project B01). The authors are grateful to G. A. Melkov and H. Yu. MusiienkoShmarova for the fruitful discussions.

**References:**

[1] D. A. Bozhko, A. A. Serga, P. Clausen, V. I. Vasyuchka, F. Heussner, G. A. Melkov, A. Pomyalov, V. S. L’vov, and B. Hillebrands, Supercurrent in a room-temperature Bose-Einstein magnon condensate, Nat. Phys. 12, 1027 (2016). [2] A. J. E. Kreil, A. Pomyalov, V. S. L’vov, H. Yu. Musiienko-Shmarova, G. A. Melkov, A. A. Serga, and B. Hillebrands, Josephson oscillations in a room-temperature Bose-Einstein magnon condensate, arXiv:1911.07802. [3] D. A. Bozhko, A. J. E. Kreil, H. Yu. Musiienko-Shmarova, A. A. Serga, A. Pomyalov, V. S. L’vov, and B. Hillebrands, Bogoliubov waves and distant transport of magnon condensate at room temperature, Nat. Commun. 10, 2460 (2019). [4] S. O. Demokritov, V. E. Demidov, O. Dzyapko, G. A. Melkov, A. A. Serga, B. Hillebrands, and A. N. Slavin, Bose-Einstein condensation of quasi-equilibrium magnons at room temperature under pumping, Nature 443, 430–433 (2006). [5] A. A. Serga, V. S. Tiberkevich, C. W. Sandweg, V. I. Vasyuchka, D. A. Bozhko, A. V. Chumak, T. Neumann, B. Obry, G. A. Melkov, A. N. Slavin, and B. Hillebrands, Bose-Einstein condensation in an ultra-hot gas of pumped magnons, Nat. Commun. 5, 3452 (2014). [6] V. E. Demidov, O. Dzyapko, S. O. Demokritov, G. A. Melkov, and A. N. Slavin, Observation of spontaneous coherence in Bose-Einstein condensate of magnons, Phys. Rev. Lett. 100, 047205 (2008). [7] A. J. E. Kreil, H. Y. Musiienko-Shmarova, S. Eggert, A. A. Serga, B. Hillebrands, D. A. Bozhko, A. Pomyalov, and V. S. L’vov, Tunable space-time crystal in room-temperature magnetodielectrics, Phys. Rev. B 100, 020406(R) (2019).

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/72224fb139fe95447f22f54475f3939d.jpg)
Fig. 1 Sketch of the experimental setup. The sample holder section shows an open waveguide with an internally mounteddielectric resonator. A bulk YIG sample is placed in an opening of the resonator together with a large detection loop to detect the radiated signals from the whole sample volume.

![](https://assets.underline.io/uploads/markdown_image/1/image/84026c2fe3ed134957adcd953bd21b38.jpg)
Fig. 2 Radiated signal of the magnon BEC measured for different times during the free decay of the system. The signals demonstrate a lorentz shape with a FWHM bandwidth of approx. 1 MHz. In normalized view it is visible that the BEC signal demonstrates an unchanged singel-state profile for a long observation period.

 Evolution of room-temperature magnon gas toward coherent Bose-Einstein condensate

In thin-films-based experiments, spin waves (SWs) are often investigated in confined geometries or as plane waves in full films. There are exceptions, such as SW channeling along domain walls [1], which are appealing in terms of SW steering. However, this approach relies on the preparation of a specific magnetic texture and transferring the SW out of it, back into the domains, seems challenging. An alternative route towards the steering of strong, channeled SWs exists, namely caustic SW beams (CSWBs). Caustic phenomena in anisotropic wave propagation correspond to sharply-defined lines/surfaces with large intensities [2]. They have been investigated in a variety of fields [2], and can be expected in micromagnetism. In thin films, caustics can arise due to the marked anisotropy of the SW dispersion relation (DR), illustrated in Fig.1. From such a plot, the direction θv of the group velocity vg=▽kω can be determined from the local normal to the curve. It can be seen in Fig.1 that a portion of the red curve (at 8.5 GHz) is almost straight, leading to a stationary θv around a value θvc for this range of wavefront angles φ. Thus, an excitation of SWs with a broad wave vector spectrum would lead to strong emission in the direction θvc. The corresponding anisotropic enhancement defines a CSWB. Such beams have so far been studied notably upon scattering of a confined SW into a wide film [4,5,6]. In the present work, we tackle theoretically the emission of CSWBs in full, soft thin films; the latter could be stimulated by the tip of a microstrip antenna. We restrict ourselves to applied fields below ferromagnetic resonance (FMR). After dimensionless rewriting of the DR, only three free parameters are left: the ratio of dipolar-exchange length to film thickness η=lex/d, the normalized SW frequency ν=ω/(γ*Js) (Js: saturation induction), and the reduced applied field h=Ba/Js. We then investigate the properties of caustic points numerically and analytically, using suitable approximations. An experimental situation corresponds to fixed film thickness; we therefore record the caustic wavenumbers (WNs) kc*d, beam directions θvc and wavefront directions φc as a function of ν and h, at fixed η. As the example in Fig.2 shows, caustic points can exhibit a rich behaviour. Starting with the caustic WNs, one can see a low-frequency, low-field pocket in the dipolar-dominated regime. Above its sharp boundary, a relatively wide band appears, corresponding to kc*d varying slowly in the dipolar-exchange regime. A final transition brings kc*d into the exchange-dominated regime; the latter has an upper boundary above which no caustic point exists (blue region in Fig.2). The map of φc(h,ν) displays a similar aspect. In the bottom pocket, the caustic wavefront angle is almost constant, with a numerically found limit of about 54.7°. Our analytical approximation yields a value of arccos(1/√3)≈54.7°, in excellent agreement. The corresponding limit for θvc is numerically 109° and 103° from analytics. In the dipolar-exchange band, by contrast with kc*d, φc varies significantly and saturates at 90° in the exchange-dominated region. This saturation is in stark correlation to that of the caustic beam direction θvc, which also goes to 90°. All the above properties can be understood from the geometrical evolution of the DR curve when ν increases, as illustrated in Fig.1. The markers on the curves correspond to their caustic point (2.5 GHz omitted for clarity). At the bottom pocket's boundary, the tangent to the DR at kc*d passes close to the origin: hence, ∂kc/∂φc is large. In the exchange-dominated regime, the curve flattens near φ=π/2. This accelerates the increase of kc*d (cf. curves at 16 and 18.5 GHz) while bringing θvc and φc to π/2 at a certain threshold frequency. Beyond the latter, the curve rounds more and more: θv can no longer be stationary, thus, no caustic point exist. From this investigation, we can thus predict two very different types of CSWBs. At the low-kc pocket's upper boundary, due to the very straight and oblique DR curve, the CSWB should feature a broad wavelength spectrum. By contrast, at the upper boundary of the caustic band, the CSWB's wavelength spectrum should be much narrower. Indeed, the DR at kc*d is tangent to a circle k*d=cst. In addition, since this CSWB consists of two beams with overlapping directions, its amplitude should be correspondingly larger. This phenomenon has been studied theoretically by Kim et al. [7]. The first type of CSWB should be invisible in magneto-optical microscopy, but Brillouin light scattering should reveal the broadband SW beam. The second type of CSWB would require time-resolved Scanning Transmission X-ray Microscopy due to the higher kc.

**References:**

[1] V. Sluka, T. Schneider, R. A. Gallardo et al., Nature Nanotechnology, Vol.14, 4, pp.328-333 (2019) [2] Y. A. Kravtsov and Y. I. Orlov, "Caustic, Catastrophes and Wave Fields", Springer-Verlag 1993 [3] B. A. Kalinikos and A. N. Slavin, Journal of Physics C: Solid State Physics, Vol.19, 7013, pp.7013-7033 (1986) [4] V. E. Demidov, S. O. Demokritov, D. Birt et al., Physical Review B, Vol.80, 014429 (2009) [5] T. Schneider, A. A. Serga, A. V. Chumak et al., Physical Review Letters, Vol.104, 197203 (2010) [6] F. Heussner, A. A. Serga, T. Brächer et al., Applied Physics Letters, Vol.111, 122401 (2017) [7] J.-V. Kim, R. L. Stamps and R. E. Camley, Physical Review Letters, Vol.117, 197204 (2016)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/015b984df791782c0abb0d98462393a9.jpg)
Fig.1: Polar plot of the normalized SW wave number k*d (d: film thickness) as a function of the angle φ from the applied field to the wave vector. The DRs are calculated from the model by Kalinikos and Slavin [3], for an applied induction Ba of 20 mT, frequencies ω/(2π) of 2.5, 8.5, 11, 13.5, 16 and 18.5 GHz, a reduced gyromagnetic ratio γ/(2π)=29.3 GHz/T, saturation induction Js=μ0*Ms=0.92 T, film thickness 60 nm and dipolar-exchange length lex=6.2 nm. Owing to the DR's symmetries, the curves shown here generates the whole polar plots by line symmetry around the quadrant boundaries.

![](https://assets.underline.io/uploads/markdown_image/1/image/80218c582c1cedf81dd66f75f10ca21a.jpg)
Fig.2: Gray-level map of the normalized caustic wave number kc*d as a function of h and v, for η=0.10355. The yellow curve corresponds to FMR; the red filled region below is not considered here. In the top left corner's blue filled region, no caustic points exist.

 Investigation of Caustic Spin Wave Beams in Soft Thin Films

Bose-Einstein condensate is a collective phenomenon which takes place when many bosons – particles having integer value of spin – experience transition to the same single quantum state. The famous example is formation of Cooper pairs of electrons, responsible for the superconducting properties of some materials at extremely low temperatures. Magnons – quasi-particles corresponding to spin waves propagating in magnetic media – are bosons as well. Hence, if we describe oscillation of magnetization as a set of magnons, the phenomenon like Bose-Einstein condensation should also exist in this case. Indeed, the Bose-Einstein condensation of magnons at room temperature has been observed under parametric pumping in thick ferrite films [1], and, recently, by rapid cooling in ultra- thin films [2]. The stability of Bose-Einstein condensate of magnons (mBEC) is determined by the nonlinear interaction between magnons. This includes both interaction between magnons in the same spectral minimum (self-interaction), and the interaction between magnons belonging to two different spectral minima (cross-interaction). mBEC can be stable if the coefficient of nonlinear interaction is positive, i.e. if the interaction is repulsive [3]. It is well known that the self-interaction between magnons in relatively thick films is attractive [3]. However, mBEC has been experimentally proven to be stable [1, 2, 4]. It was shown in [5] that coefficient of nonlinear interaction in mBEC is negative, but rather small, so relatively strong repulsive interaction between magnons in different spectral minima may provide stability to mBEC. Recently, it has been also shown [6] that it is possible to separate mBEC in two parts, each containing magnons from only one spectral minimum, which means that mBEC in each of the minima is stable, and this stability is independent of the strong cross-interaction of magnons from different minima. Thus, the theory developed in [5] cannot be used to explain stability of separated mBEC. Also, the theory [5] assumes a uniform profile of a magnon mode across the film thickness, and infinite in-plane sizes of the magnetic film sample. Both these simplifications are, generally, incorrect. Due to the long-range nature of the dipolar interaction, finite-size effects may have a significant impact on the nonlinear interactions of magnons [4]. Here, we present a simple, but rather accurate model of the nonlinear interactions in mBEC that takes into account the finite-size effects. Using Landau-Lifshits equation and vector Hamiltonian approach [7], we derived approximate analytical expressions for the linear dispersion characteristics and nonlinear interaction coefficients of magnons near the minima of the magnon spectrum (i.e. in the mBEC region). We showed that magnons undergoing mBEC can be described as a gas of weakly-interacting bosonic particles in an infinite potential well formed by a ferromagnetic film. The rest energy of the magnons in mBEC is determined by the dipolar interaction inside a film sample. This leads to a strong anisotropy of the effective mass of magnons in the magnetic film. In the direction along the applied in-plane magnetic field, the effective mass is m∥ = hMs/(32πγA) (where Ms is the saturation magnetization, h is the Planck constant, γ is the gyromagnetic ratio, and A is the exchange stiffness). For yttrium-iron garnet (YIG), this “longitudinal” mass is m∥ ≈ 1.5×10-30 kg ≈ 1.6 me (me is the electron mass). In the directions perpendicular to the applied field magnons are described by the “perpendicular” mass m⊥ = (18λ/d)m∥, which depends on the ratio of the exchange length λ = (2A/μ0Ms2)1/2 to the thickness of the film d. For typical experimental conditions m⊥ « m∥; for example, m⊥ ≈ 0.06 m∥ in a YIG film of the thickness d = 5 μm. The huge anisotropy of the effective mass leads to the anisotropy of the dynamical mBEC properties. In particular, the speed of the Bogolyubov waves [8] depends strongly on the direction of the wave propagation. Since the perpendicular mass m⊥ depends on the thickness of the film, it is possible to achieve the inverse mass relation m⊥ &gt; m∥ in ultra-thin YIG films with d &lt; 300 nm. Under the assumption of totally pinned spins, which is an accurate approximation in the mBEC region, we derived approximate analytical expressions for the nonlinear frequency shift due to the self- and cross- interactions in mBEC: Δf = (Fself + 2Fcross)n; Fself = F0 (2Nd – 3πλ/d√2); Fcross = F0. Here F0 = γ2μ0h/4π2 is the normalisation constant, n is the magnon density, Nd is the component of the demagnetization tensor N = diag(Nx, Ny, Nz) corresponding to the direction along the applied in-plane magnetic field. These expressions show that the nonlinear cross-interaction stays large and positive independently of the confinement of the sample in the applied field direction, while the self-interaction coefficient changes its sign when Nd become greater than the critical value Ncr: Ncr = (3π/2√2)(λ/d). The result explains possibility to separate mBEC into two stable components corresponding to the different minima of the mBEC spectrum [4, 6]. The developed model allows one to make simple and accurate predictions about the stability of the mBEC depending on the shape of the sample used, and to describe dynamics of fluctuations and waves of magnon density in the mBEC. Also, it makes possible to directly apply theoretical methods developed to describe condensates of atoms to study the mBEC dynamics, and, therefore, it might be very useful in further investigations of coherent magnonic phenomena.

**References:**

[1] S. O. Demokritov, V. E. Demidov, O. Dzyapko et al., Nature, vol. 443, pp. 430-433, 2006. [2] M. Schneider, T. Brächer, D. Breitbach et al., Nat. Nanotechnol., vol. 15, pp. 457–461, 2020. [3] V. S. L’vov, Wave turbulence under parametric excitation, Springer Series in Nonlinear Dynamics (Springer, Berlin, 1994). [4] I. V. Borisenko, B. Divinskiy, V. E. Demidov et al., Nat. Commun., vol. 11, no. 1691, 2020. [5] O. Dzyapko, I. Lisenkov, P. Nowik-Boltyk et al., Phys. Rev. B, vol. 96, no. 064438, 2017. [6] I. V. Borisenko, V. E. Demidov, V. L. Pokrovsky et al., Sci. Rep., vol. 10, no. 14881, 2020. [7] V. Tyberkevych, A. Slavin, P. Artemchuk, et al., arXiv:2011.13562 (2020). [8] D. A. Bozhko, A. J. E. Kreil, H. Yu. Musiienko-Shmarova et al., Nat. Commun., vol 10, no. 2460, 2019.

**Images:**

 A Model for Description of Linear Properties and Stability of Bose-Einstein Condensate of Magnons at Room Temperature

The magnetism in curved geometries is attracting attention because of several theoretical predictions with possible potential applications, such as a curvature induced effective Dzyaloshinskii-Moriya like interaction [1]. Within this setting, analogously to a geometric curvature, a curvature induced by a gauge field [2] is a fruitful aspect to consider in the interaction of the magnetization with an applied static electric field. In a quantum description of the motion of a magnetic moment, an electric field does not modify the energy but it rather modifies the linear momentum, therefore introducing an additional phase for the corresponding Schrödinger wave function, an effect which is known as the Aharonov-Casher’s effect [3]. The classical analog is the spin wave of a ferromagnet. It has been shown that a spin wave, which is carrying a magnetic moment, will acquire a phase when the system is subjected to an electric field [4]. This effect, even if rather small, can be experimentally observed [5]. It is therefore of interest to extend this idea to a general micromagnetic description of the problem. The aim of this research is to pose the problem of the micromagnetics under the effect of an electric field by using the so-called gauge invariance. Briefly the spin-waves, which are small oscillations, deviate from the uniform magnetization with respect to a local reference frame and around the ez direction. They interact with an applied electric field E Fig.(1) modifying the spin wave dispersion relation. Therefore, according to the so-called local exchange invariance [6], we propose a phase shift model, in the exchange spin waves regime, in order to possibly describe and interpret the data shown in [5]. More in details the local gauge symmetry is approximately a local invariance property (because of its thermodynamic origin), of the lagrangian density of the magnetization m(x, t) of a ferromagnet. It is known that it is invariant with respect to the SO(3) global symmetry [7]. In our case this symmetry reduces to a unitary representation of the SO(2) group, (i.e., U(1)). Due to the reason that this symmetry has to be local (i.e., to be position dependent) the invariance of the lagrangian density is broken unless introducing a gauge field able to solve the technical problem of the parallel transport of the magnetization vector. Therefore we show that a particular orientation of a reference frame has no physical relevance. In fact, gauge invariance should occur whenever one can define non-collinear, local reference frames. In our model, the orientation of the local non-coordinate reference frames cannot be uniquely defined because of the presence of an electric field. Summarizing in our invariant gauge formulation the reference frames’ orientation is unspecified with respect to a local phase which defines an invariance property of the exchange interaction terms in the lagrangian density of the magnetization m(x, t). The Lagrangian density of a ferromagnet, interacting with an electric field, is transformed into a new Lagrangian density upon a formal redefinition of the standard partial derivative. Moreover the transformation group, which expresses this invariance, imposes definite restrictions on the dispersion relation that at the first order in a Tylor expansion was previously found to be ω=ω(ky)-γLc-2∂ω/∂kyEx [4], with γL the gyromagnetic ratio and c the speed of light. Therefore our findings point to a more advanced theoretical interpretation with respect to previous discoveries [4] in order to drive experiments in manipulating spin waves and developing electrically tunable magnonic devices.

**References:**

[1] R. Streubel et al., J. Phys. D: Appl. Phys. 49, 363001 (2016). [2] S.G. Tan, et al., Physics Reports, Volume 882, Pages 1-36, (2020). [3] Y. Aharonov and A. Casher, Phys. Rev. Lett. 53, 319, (1984). [4] V. Basso and P. Ansalone, EPL, Vol. 130, Number 1, Article 17008, (2020). [5] X. Zhang, T.Liu, M.E. Flatté and H.X. Tang Phys. Rev. Lett. 113, (2014). [6] I.E. Dzyaloshinskii and G.E.Volovik, J.Physique, 39, 693, (1978). [7] W. F. Brown, Magnetoelastic interactions, pp. 26 and 79, (Vol. 9), Berlin: Springer, (1966).

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/62bbb322a9e11ec137f86fd168238d14.jpg)
Fig. 1 The system under study is a two dimensional infinite ferromagnetic layer with primary magnetization along the direction ez , an external electric field is applied perpendicularly to both the magnetization and k spin-wave vector.

 Effect of the Local Exchange Invariance on the Magnetization Dynamics in a Ferromagnet

wo recent reports of the Münster University experimental team led by S.O. Demokritov [Borisenko et al., Nat. Comm. 2020, Borisenko et al., Sci. Rep. 10, 14881 (2020)] displayed several important facts contradicting to the existing theories of the Bose-Einstein condensate of magnons (BECM) [Tupitsyn et al. 2008, Rezende 2009, F. Li et al. 2013]. We present simplified theoretical arguments to determine what are properties of the uniform stationary BECM established under the action of permanent parametric pumping that follows from the experimental facts. We point out that the complete equilibrium was not established in the magnon system because the inter-condensates relaxation time is much longer than the lifetime of condensate magnons. Since the magnons repulse each other, the uniform stationary state of the condensate does not collapse. If the inter-condensates relaxation processes are negligible, then the stationary state of the condensate must be symmetric since the processes of parametric pumping and those responsible for finite magnons lifetime are identical for the two condensates. The weak inter- condensates relaxation processes lead to a weak spontaneous violation of the use of reflection symmetry. This prediction agrees with the inter-condensate interference structure of the condensate discovered by Novik-Boltyk et al. [Novik- Boltyk 2012]

**References:**

 Borisenko, I., Divinskiy, B., Demidov, V. et al. Direct evidence of spatial stability of Bose-Einstein condensate of magnons. Nat Commun 11, 1691 (2020). Borisenko, I.V., Demidov, V.E., Pokrovsky, V.L. et al. Spatial separation of degenerate components of magnon Bose–Einstein condensate by using a local acceleration potential. Sci Rep 10, 14881 (2020) Tupitsyn, I. S., Stamp, P. C. E. & Burin, A. L. Stability of Bose–Einstein condensates of hot magnons in yttrium iron garnet films. Phys. Rev. Lett. 100, 257202 (2008). Rezende, S. M. Theory of coherence in Bose–Einstein condensation phenomena in a microwave-driven interacting magnon gas. Phys. Rev. B 79, 174411 (2009) Li, F., Saslow, W. M. & Pokrovsky, V. L. Phase diagram for magnon condensate in yttrium iron garnet film. Sci. Rep. 3, 1372 (2013) Nowik-Boltyk, P., Dzyapko, O., Demidov, V. E., Berloff, N. G. & Demokritov, S. O. Spatially non-uniform ground state and quantized vortices in a two-component Bose–Einstein condensate of magnons. Sci. Rep. 2, 482 (2012)

**Images:**

 Stationary state of Bose-Einstein condensate of magnons: theory and experiment

Due to low transport dissipation property, magnon was considered as a candidate of next-generation carrier of spintronic industry. In 2016, the van Wees group[1] found an interesting difference between electrically and thermally excited magnons on the nonlocal transport in a very short range. Unlike electrically excited magnons, thermally excited magnons showed a sign-reversal in less than about 300 nm distance between heat injector and magnons detector. Some people developed a bulk SSE theory to explain this phenomenon. According to this theory, a heat flow Jq in YIG will excite a thermal magnon flow Jm,q along with it, A diffusive magnon flow is induced to balance the thermal magnon flow, until the system reaches a steady-state. The sign-reversal derived from a competition of these two magnon flow. While in our point of view, this theory may not reach the nature of transmission properties of thermally excited magnons. To clarify the physical essence and gain complete information in the reciprocal space of this process, we adapted mesoscopic Boltzmann method to study magnon transports[2]. In the method, like phonon, we introduced a special scattering process named “Normal Scattering”, which prevents magnons’ momenta during scattering process. When normal scattering is dominant, magnons turned to a uniform velocity. This uniform velocity makes magnons flux acting as a viscous fluid. Based on Boltzmann method, we developed a new diffusion method of magnons viscous fluid to simplify the calculation and found its nonlinear property. Two-dimensional figures of magnon flux showed the viscosity of magnon fluid created two eddies near the heat source. And the numerical result could fit Experimental data precisely. Our results show magnon flow may be controlled like a viscous fluid by applied magnetic field, which has promising applications in nanoscale magnon-based spintronic devices.

**References:**

1, J. Shan, L. Cornelissen, N. Vlietstra, J. Youssef, T. Kuschel, R. Duine, and B. van Wees, Phys. Rev. B 94, 174437 (2016) 2, T. Liu, W. Wang & J. Zhang, Phys. Rev. B, 99, 214407 (2019).

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/6442af17d25c4eca7d4827e3e6b415bc.jpg)

 Novel Transport Properties of Viscous-Fluid type Magnon in Magnetic Thin Film

Cavity magnonics built on strongly coupled cavity photons and magnons has gradually demonstrated its unique advantages in fundamental and applied research in the past few years. It has several advantages, including flexible turnability, excellent controllability, and high compatibility. Furthermore, a versatile platform based on coherently coupled microwave photons, magnons, phonons, superconducting qubits, and optical photons has begun to take shape. The hybrid system is expected to be applied in quantum information processing, transfer, and storage. Before 2018, all experiments were carried out in the case of coherent coupling between cavity photons and magnons. In 2018, an intriguing dissipative coupling between cavity photon and magnon was observed for the first time, which originated from the cooperative dissipation of the cavity mode and magnon mode. Unlike the coherent coupling case, where the spectrum is shown as an anti-crossing between cavity mode and magnon mode, the spectrum is shown as a level attraction in the case of dissipative coupling. The revelation of dissipative coupling greatly enhances the richness and functionality of the cavity magnonics and stimulates some fundamental research. We will introduce this trend with two recent works from our group. After revealing the dissipative coupling mechanism, we first realized nonreciprocity and unidirectional invisibility in cavity magnonics by utilizing the interference effect between the coherent and dissipative couplings. The isolation ratio can be relatively large with optimized small insertion loss. With the dissipative coupling mechanism and magnon mode linewidth engineering technique, we construct an anti-parity-time (APT) symmetric cavity magnonics system. Besides the dissipative coupling, the APT symmetric system also needs (i) the cavity mode and magnon mode have the opposite frequency, which can be effectively realized with a detuned cavity magnonics system in the rotating frame, (ii) the same damping or gain rates of the cavity mode and magnon mode, which can be engineered by adjusting the damping rate of the magnon mode to match that of the cavity mode. Further, we observed the exceptional points in this APT symmetric cavity magnonics system, which are the transition points between the PT-symmetry-preserved and PT-symmetry-broken phases. Between two EPs, the maximal coherent superposition of photon and magnon states is robustly sustained by the preserved APT symmetry. Moreover, we observed another kind of singularity, arising from the dissipative coupling of two antiresonances, is an unconventional bound state in the continuum (BIC). At the settings of BICs, the coupled system exhibits infinite discontinuities in the group delay. We find that both singularities coexist at the equator of the eigenvector mapped Bloch sphere, revealing a unique hybrid state that simultaneously exhibits the maximal coherent superposition and slow light capability. We expect to explore more interesting physics and applications based on the dissipative coupling in cavity magnonics.

**References:**

1. H. Huebl, et al, Phys. Rev. Lett. 111, 127003 (2013). 2. Y. Tabuchi, wt al, Phys. Rev. Lett. 113, 083603 (2014). 3. X. Zhang, et al, Phys. Rev.Lett. 113, 156401 (2014). 4. M. Goryachev, et al, Phys. Rev. Applied 2, 054002 (2014). 5. L. Bai, et al, Phys. Rev. Lett. 114, 227201 (2015). 6. Y.-P. Wang, Phys. Rev. Lett. 123, 127202 (2019). 7. Y. Yang, Phys. Rev. Lett. 125, 147202 (2020).

**Images:**
