Introduction&lt;br/&gt;Multiferroic materials have been attracting much attention because they have multiple ordered (ferroelastic, ferroelectric, and ferromagnetic) states. In particular, magnetic and ferroelectric material has a property that magnetization &lt;i&gt;M&lt;/i&gt; (electric polarization &lt;i&gt;P&lt;/i&gt;) can be controlled by electric &lt;i&gt;E&lt;/i&gt; (magnetic &lt;i&gt;H&lt;/i&gt;) field. Such property is called “magnetoelectric (ME) effect”. In magnetic and ferroelectric material, there is also a possibility of observing an optical response that the rate of absorption is different between the cases that light enters from one direction and the opposite direction. Such a large nonreciprocal response in the visible light region was discovered in CuB&lt;sub&gt;2&lt;/sub&gt;O&lt;sub&gt;4 &lt;/sub&gt;[1]. The observed nonreciprocal response in light is thought to be originated from dynamical AC ME response.&lt;br/&gt;The present compounds, CaBa&lt;i&gt;M&lt;/i&gt;&lt;sub&gt;4&lt;/sub&gt;O&lt;sub&gt;7&lt;/sub&gt; (&lt;i&gt;M&lt;/i&gt;=Co, Fe), have been attracting interest for their nontrivial magnetism because of the geometrically frustrated crystal structure consisting of triangular and Kagome layers. From the viewpoints of the studies of multiferroics, we have expected that the magnetic ordering couples with the spontaneous electric polarization &lt;i&gt;P&lt;/i&gt; due to the crystal structure with a polar point-group of &lt;i&gt;mm&lt;/i&gt;2. Indeed, we have observed the change of &lt;i&gt;P&lt;sub&gt;c&lt;/sub&gt;&lt;/i&gt; induced by the weak ferromagnetic ordering in CaBaCo&lt;sub&gt;4&lt;/sub&gt;O&lt;sub&gt;7&lt;/sub&gt; [2]. Then the magnetic-field &lt;i&gt;H&lt;sub&gt;ab&lt;/sub&gt;&lt;/i&gt;-induced giant variation in &lt;i&gt;P&lt;sub&gt;c&lt;/sub&gt;&lt;/i&gt; was reported and the magnetostriction mechanism was proposed to explain the observed giant ME effect [3]. Also in the case of CaBaFe&lt;sub&gt;4&lt;/sub&gt;O&lt;sub&gt;7&lt;/sub&gt;, the ME coefficient &lt;i&gt;&lt;sup&gt;H&lt;/sup&gt;α&lt;sub&gt;cc&lt;/sub&gt;&lt;/i&gt; defined as &lt;i&gt;△P&lt;sub&gt;c&lt;/sub&gt;&lt;/i&gt;=&lt;i&gt;&lt;sup&gt;H&lt;/sup&gt;α&lt;sub&gt;cc&lt;/sub&gt;&lt;/i&gt;&lt;i&gt;H&lt;sub&gt;c&lt;/sub&gt;&lt;/i&gt; with a maximum value of 39 ps/m was reported for the measurements of &lt;i&gt;H&lt;sub&gt;c&lt;/sub&gt;&lt;/i&gt;-induced change of &lt;i&gt;P&lt;sub&gt;c&lt;/sub&gt;&lt;/i&gt; at 80 K below the ferrimagnetic transition temperature of 275 K [4].&lt;br/&gt;In this work, we have systematically investigated nonreciprocal DC ME response, i.e., crystalline (polar) direction dependence of ME coefficients for CaBa&lt;i&gt;M&lt;/i&gt;&lt;sub&gt;4&lt;/sub&gt;O&lt;sub&gt;7&lt;/sub&gt; (&lt;i&gt;M&lt;/i&gt;=Co, Fe) single crystals. Especially, we focused on the electric-field (&lt;i&gt;E&lt;sub&gt;c&lt;/sub&gt;&lt;/i&gt;)-induced magnetization (&lt;i&gt;M&lt;sub&gt;ab&lt;/sub&gt;&lt;/i&gt; or&lt;i&gt; M&lt;sub&gt;c&lt;/sub&gt;&lt;/i&gt;) in CaBa&lt;i&gt;M&lt;/i&gt;&lt;sub&gt;4&lt;/sub&gt;O&lt;sub&gt;7&lt;/sub&gt; (&lt;i&gt;M&lt;/i&gt;=Co, Fe), which had almost not yet been performed.&lt;br/&gt;&lt;br/&gt;Results and Discussion&lt;br/&gt;Figure 1 shows the Schematic crystal structure of CaBa&lt;i&gt;M&lt;/i&gt;&lt;sub&gt;4&lt;/sub&gt;O&lt;sub&gt;7&lt;/sub&gt; (&lt;i&gt;M&lt;/i&gt; = Co, Fe). The space group of CaBaCo&lt;sub&gt;4&lt;/sub&gt;O&lt;sub&gt;7&lt;/sub&gt; at room temperature is orthorhombic &lt;i&gt;Pbn&lt;/i&gt;2&lt;sub&gt;1&lt;/sub&gt;, which is distorted and lowered symmetry from the higher one of hexagonal &lt;i&gt;P&lt;/i&gt;6&lt;sub&gt;3&lt;/sub&gt;&lt;i&gt;mc&lt;/i&gt;. Its (magnetic) point group is (&lt;i&gt;m&lt;/i&gt;’&lt;i&gt;m&lt;/i&gt;2’) &lt;i&gt;mm&lt;/i&gt;2. Those of CaBaFe&lt;sub&gt;4&lt;/sub&gt;O&lt;sub&gt;7&lt;/sub&gt; are &lt;i&gt;Pbn&lt;/i&gt;2&lt;sub&gt;1&lt;/sub&gt; and &lt;i&gt;mm&lt;/i&gt;2, which are the same as CaBaCo&lt;sub&gt;4&lt;/sub&gt;O&lt;sub&gt;7&lt;/sub&gt; [2,4]. Its magnetic point group is unknown yet. Both materials have quasi-triangular lattices and quasi-Kagome ones stacked along the &lt;i&gt;c&lt;/i&gt;-axis direction. There exists multidomain structure within the orthorhombic &lt;i&gt;ab&lt;/i&gt; plane in spite of no such one in the &lt;i&gt;c&lt;/i&gt; axis. A spontaneous electric polarization along the &lt;i&gt;c&lt;/i&gt; axis (&lt;i&gt;P&lt;sub&gt;c&lt;/sub&gt;&lt;/i&gt;) is expected from the polar point group of &lt;i&gt;mm&lt;/i&gt;2.&lt;br/&gt;Figure 2(i) shows the electric field dependence of the magnetization of CaBaCo&lt;sub&gt;4&lt;/sub&gt;O&lt;sub&gt;7&lt;/sub&gt; in constant magnetic fields. The magnetic field (&lt;i&gt;H&lt;sub&gt;ab&lt;/sub&gt;&lt;/i&gt;) was applied within the magnetic easy &lt;i&gt;ab&lt;/i&gt; plane perpendicular to the &lt;i&gt;c&lt;/i&gt; axis, and the electric field (&lt;i&gt;E&lt;sub&gt;c&lt;/sub&gt;&lt;/i&gt;) was applied along the &lt;i&gt;c&lt;/i&gt; axis which is the direction of spontaneous electric polarization (&lt;i&gt;P&lt;sub&gt;c&lt;/sub&gt;&lt;/i&gt;). The configuration among the external magnetic field, electric field, and crystalline direction (spontaneous electric polarizaion) is presented in the inset of Fig. 2(ii). When the electric field is applied in the parallel direction (p) to the crystalline direction, the magnetization increases as the electric field increases. Such trends can be clearly seen as solid symbols in Fig. 2(i). Conversely, in the antiparallel (a) case, the magnetization decreases with electric field (See open symbols).&lt;br/&gt;Figure 2(ii) shows the magnetic field dependence of &lt;i&gt;&lt;sup&gt;E&lt;/sup&gt;α&lt;/i&gt;&lt;sub&gt;32&lt;/sub&gt; which is a component of linear ME tensor and defined as &lt;i&gt;M&lt;sub&gt;ab&lt;/sub&gt;&lt;/i&gt;≡&lt;i&gt;&lt;sup&gt;E&lt;/sup&gt;α&lt;/i&gt;&lt;sub&gt;32&lt;/sub&gt;&lt;i&gt;E&lt;sub&gt;c&lt;/sub&gt;&lt;/i&gt;. Depending on the configurations between the electric field and the crystal direction, &lt;i&gt;&lt;sup&gt;E&lt;/sup&gt;α&lt;/i&gt;&lt;sub&gt;32&lt;/sub&gt; shows opposite signs. The observed crystalline-direction (polarity) dependence of change in magnetization can be regarded as a DC nonreciprocal response. As is well known for the diode, nonreciprocal response is indispensable in device applications. Therefore, we explore the novel nonreciprocal phenomena as mentioned above in the present polar magnetic compounds, CaBa&lt;i&gt;M&lt;/i&gt;&lt;sub&gt;4&lt;/sub&gt;O&lt;sub&gt;7&lt;/sub&gt; (&lt;i&gt;M&lt;/i&gt; = Co, Fe), for the future application such as “thermal diode”.

**References:**

[1] M.Saito &lt;i&gt;et al.&lt;/i&gt;, J. Phys. Soc. Jpn. 77, 013705 (2008).&lt;br/&gt;[2] H. Iwamoto &lt;i&gt;et al.&lt;/i&gt;, J. Phys: Conf. Ser. 400, 032031 (2012).&lt;br/&gt;[3] V. Caignaert &lt;i&gt;et al.&lt;/i&gt;, Phys. Rev. B 88, 174403 (2013).&lt;br/&gt;[4] V. Kocsis &lt;i&gt;et al.&lt;/i&gt;, Phys. Rev. B 93, 014444 (2016).

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/ae2bea3298433e5c1ccf14561452cfc9.jpg)
Schematic crystal structure of CaBa&lt;i&gt;M&lt;/i&gt;&lt;sub&gt;4&lt;/sub&gt;O&lt;sub&gt;7&lt;/sub&gt; (&lt;i&gt;M&lt;/i&gt; = Co, Fe) projected onto the &lt;i&gt;bc&lt;/i&gt; plane (a). Its quasi-triangular (b) and quasi-Kagome layers (c) are projected onto the &lt;i&gt;ab&lt;/i&gt; plane. The rectangular boxes represent the boundaries of unit cell [2].

![](https://assets.underline.io/uploads/markdown_image/1/image/0c8e519eab7cbb2fc00b2b326156b7ec.jpg)
(i) Electric field dependence of magnetization in CaBaCo&lt;sub&gt;4&lt;/sub&gt;O&lt;sub&gt;7&lt;/sub&gt;. Solid symbols correspond to the parallel configuration between the electric field and the crystalline (polar) direction, and open ones to the antiparallel configuration. (ii) Magnetic field dependence of &lt;i&gt;&lt;sup&gt;E&lt;/sup&gt;α&lt;/i&gt;&lt;sub&gt;32&lt;/sub&gt; (≡&lt;i&gt;M&lt;sub&gt;ab&lt;/sub&gt;&lt;/i&gt;/&lt;i&gt;E&lt;sub&gt;c&lt;/sub&gt;&lt;/i&gt;) deduced from the data shown in (i). The inset is a schematic diagram of the configuration among the external magnetic/electric fields and the crystal direction.

INTERMAG 2021

 Polarity dependence of change in electric polarization (magnetization) induced by magnetic (electric) fields in CaBaM4O7(M=Co, Fe) single crystals

INTERMAG 2021 Welcome Video




<figure class="video_container">
 <iframe src="https://screencast-o-matic.com/player/crflqFVnUpZ?v=6&ff=1&title=0&controls=1" width=640 height=360 frameborder="0" allowfullscreen="true"> </iframe>
</figure>

Want to buy a ticket?

Register for INTERMAG 2021 here

[![](https://assets.underline.io/uploads/markdown_image/1/image/17ce76e7960db633258024eef8d6da7f.png)](https://intermag.org/register)

Got your ticket, but still can’t access the event?

Contact us and our team will look into it.

Introduction Multiferroic materials have been attracting much attention because they have multiple ordered (ferroelastic, ferroelectric, and ferromagnetic) states. In particular, magnetic and ferroelectric material has a property that magnetization M (electric polarization P) can be controlled by electric E (magnetic H) field. Such property is called “magnetoelectric (ME) effect”. In magnetic and ferroelectric material, there is also a possibility of observing an optical response that the rate of absorption is different between the cases that light enters from one direction and the opposite direction. Such a large nonreciprocal response in the visible light region was discovered in CuB2O4 [1]. The observed nonreciprocal response in light is thought to be originated from dynamical AC ME response. The present compounds, CaBaM4O7 (M=Co, Fe), have been attracting interest for their nontrivial magnetism because of the geometrically frustrated crystal structure consisting of triangular and Kagome layers. From the viewpoints of the studies of multiferroics, we have expected that the magnetic ordering couples with the spontaneous electric polarization P due to the crystal structure with a polar point-group of mm2. Indeed, we have observed the change of Pc induced by the weak ferromagnetic ordering in CaBaCo4O7 [2]. Then the magnetic-field Hab-induced giant variation in Pc was reported and the magnetostriction mechanism was proposed to explain the observed giant ME effect [3]. Also in the case of CaBaFe4O7, the ME coefficient Hαcc defined as △Pc=HαccHc with a maximum value of 39 ps/m was reported for the measurements of Hc-induced change of Pc at 80 K below the ferrimagnetic transition temperature of 275 K [4]. In this work, we have systematically investigated nonreciprocal DC ME response, i.e., crystalline (polar) direction dependence of ME coefficients for CaBaM4O7 (M=Co, Fe) single crystals. Especially, we focused on the electric-field (Ec)-induced magnetization (Mab or Mc) in CaBaM4O7 (M=Co, Fe), which had almost not yet been performed. Results and Discussion Figure 1 shows the Schematic crystal structure of CaBaM4O7 (M = Co, Fe). The space group of CaBaCo4O7 at room temperature is orthorhombic Pbn21, which is distorted and lowered symmetry from the higher one of hexagonal P63mc. Its (magnetic) point group is (m’m2’) mm2. Those of CaBaFe4O7 are Pbn21 and mm2, which are the same as CaBaCo4O7 [2,4]. Its magnetic point group is unknown yet. Both materials have quasi-triangular lattices and quasi-Kagome ones stacked along the c-axis direction. There exists multidomain structure within the orthorhombic ab plane in spite of no such one in the c axis. A spontaneous electric polarization along the c axis (Pc) is expected from the polar point group of mm2. Figure 2(i) shows the electric field dependence of the magnetization of CaBaCo4O7 in constant magnetic fields. The magnetic field (Hab) was applied within the magnetic easy ab plane perpendicular to the c axis, and the electric field (Ec) was applied along the c axis which is the direction of spontaneous electric polarization (Pc). The configuration among the external magnetic field, electric field, and crystalline direction (spontaneous electric polarizaion) is presented in the inset of Fig. 2(ii). When the electric field is applied in the parallel direction (p) to the crystalline direction, the magnetization increases as the electric field increases. Such trends can be clearly seen as solid symbols in Fig. 2(i). Conversely, in the antiparallel (a) case, the magnetization decreases with electric field (See open symbols). Figure 2(ii) shows the magnetic field dependence of Eα32 which is a component of linear ME tensor and defined as Mab≡Eα32Ec. Depending on the configurations between the electric field and the crystal direction, Eα32 shows opposite signs. The observed crystalline-direction (polarity) dependence of change in magnetization can be regarded as a DC nonreciprocal response. As is well known for the diode, nonreciprocal response is indispensable in device applications. Therefore, we explore the novel nonreciprocal phenomena as mentioned above in the present polar magnetic compounds, CaBaM4O7 (M = Co, Fe), for the future application such as “thermal diode”.

**References:**

[1] M.Saito et al., J. Phys. Soc. Jpn. 77, 013705 (2008). [2] H. Iwamoto et al., J. Phys: Conf. Ser. 400, 032031 (2012). [3] V. Caignaert et al., Phys. Rev. B 88, 174403 (2013). [4] V. Kocsis et al., Phys. Rev. B 93, 014444 (2016).

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/ae2bea3298433e5c1ccf14561452cfc9.jpg)
Schematic crystal structure of CaBaM4O7 (M = Co, Fe) projected onto the bc plane (a). Its quasi-triangular (b) and quasi-Kagome layers (c) are projected onto the ab plane. The rectangular boxes represent the boundaries of unit cell [2].

![](https://assets.underline.io/uploads/markdown_image/1/image/0c8e519eab7cbb2fc00b2b326156b7ec.jpg)
(i) Electric field dependence of magnetization in CaBaCo4O7. Solid symbols correspond to the parallel configuration between the electric field and the crystalline (polar) direction, and open ones to the antiparallel configuration. (ii) Magnetic field dependence of Eα32 (≡Mab/Ec) deduced from the data shown in (i). The inset is a schematic diagram of the configuration among the external magnetic/electric fields and the crystal direction.
