In order to address the high demand for data in information technology, spintronics proposes attractive solutions. The most recent are based on the exploitation of the spin-orbit coupling of non-magnetic heavy metals to use the spin-orbit torque (SOT) exerted on the magnetic layer attached to the heavy metal [1,2]. However, magnetic material can be a source of spin current as well. We studied GdFeCo alloys in which the 5d band of Gd induces large spin-orbit couplings.&lt;br/&gt;&lt;br/&gt;In GdFeCo, we can identify spin currents of two different symmetries, SAHE-like [3,4] and SHE-like [5] corresponding respectively to the Spin Anomalous Hall Effect and Spin Hall Effect symmetries [6]. Only the second one can generate torques on the magnetic layer. In this work [6], we present a detailed study of different systems to account for the &lt;i&gt;self-torque&lt;/i&gt; in GdFeCo/Cu. The characterization of the &lt;i&gt;self-torque&lt;/i&gt; is carried out by means of harmonic Hall voltage measurements in samples where the GdFeCo layer exhibits out of plane magnetization. The samples were grown by magnetron sputtering and standard optical lithography was used to micro fabricate the Hall bar devices.&lt;br/&gt;&lt;br/&gt;We focus first on the temperature dependence of the effective fields associated to the &lt;i&gt;self-torque&lt;/i&gt; in GdFeCo/Cu. As shown in Fig. 1, the amplitude of the damping-like (DL) effective field increases when the temperature approaches the magnetization compensation temperature T&lt;sub&gt;CM&lt;/sub&gt; and changes sign when crossing the last. The field-like (FL) effective field shows the same behavior. Even far from T&lt;sub&gt;CM&lt;/sub&gt;, the efficiency H&lt;sub&gt;DL&lt;/sub&gt;/J&lt;sub&gt;GdFeCo&lt;/sub&gt;=2.10&lt;sup&gt;-10&lt;/sup&gt; Oe/(A/m&lt;sup&gt;2&lt;/sup&gt;) is in the order of magnitude or higher than with the use of most of the heavy metals [1]. However, the associated DL and FL torques do not increase as the effective fields when approaching T&lt;sub&gt;CM&lt;/sub&gt; but do change sign.&lt;br/&gt;&lt;br/&gt;Furthermore, in a second set of experiments, we compare the &lt;i&gt;self-torque&lt;/i&gt; in GdFeCo/Cu with torques in GdFeCo/Cu/Pt and GdFeCo/Cu/Ta structures. The supplementary heavy metal allows an additional torque generation on the magnetization via the SHE and, in addition, acts as a spin-sink of the spin current emmitted by GdFeCo. The improvement of the GdFeCo-emitted-spin-current absorption allowed by this extra layer is the source of a magnified DL &lt;i&gt;self-torque. &lt;/i&gt;We found that the efficiency associated to the &lt;i&gt;self-torque &lt;/i&gt;is increased by a factor of 4 in the GdFeCo/Cu/Ta structure and a factor of 7 in the GdFeCo/Cu/Pt structure compared to the &lt;i&gt;self-torque &lt;/i&gt;in GdFeCo/Cu as shown in Fig. 2.&lt;br/&gt;&lt;br/&gt;Therefore, we conclude that sizeable spin-orbit effects can arise from quasi-isolated magnetic layer with strong spin-orbit coupling such as GdFeCo. These effects give rise to large self-induced effective fields enhanced near the magnetization compensation temperature. The addition of a heavy metal, which improves the spin-current absorption outside the ferrimagnetic layer, enhances the DL &lt;i&gt;self-torque&lt;/i&gt;. This paves the way for new architectures to achieve and exploit SOT switching as well as free heavy metal SOT switching and skyrmions manipulation.

**References:**

[1] A. Manchon, J. Zelezný, IM. Miron, Rev. Mod. Phys., Vol. 91, p.035004 (2019)&lt;br/&gt;[2] TH. Pham, SG. Je, P. Vallobra, Phys. Rev. Appl., Vol. 9, p.064032 (2018)&lt;br/&gt;[3] T. Taniguchi, J. Grollier, and MD. Stiles, Phys. Rev. Appl., Vol. 3, p.044001 (2015)&lt;br/&gt;[4] S. Lihama, T. Taniguchi, K. Yakushiji, Nat. Elecron., Vol. 1, p.120 (2018)&lt;br/&gt;[5] VP. Amin, PM. Haney, and MD. Stiles, J. Appl. Phys., Vol. 128, p.151101 (2020)&lt;br/&gt;[6] D. Céspedes-Berrocal, H. Damas, S. Petit-Watelot, Adv. Materials (2021)&lt;br/&gt;https://doi.org/10.1002/adma.202007047 ArXiv: 2010.09137

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/fe33515fd84a80cc01e5250c8d328a21.jpg)
Fig. 1 : Temperature dependance of the damping-like efficiency in Gd&lt;sub&gt;27&lt;/sub&gt;Fe&lt;sub&gt;50.9&lt;/sub&gt;Co&lt;sub&gt;10.2&lt;/sub&gt;(10nm)/Cu(2nm)/AlOx(2.5nm). The magnetization compensation temperature T&lt;sub&gt;CM&lt;/sub&gt; is depicted by the background change of color. The DL effective field diverges near T&lt;sub&gt;CM &lt;/sub&gt;as the magnetization is zero and its sign is reversed above T&lt;sub&gt;CM&lt;/sub&gt;.

![](https://assets.underline.io/uploads/markdown_image/1/image/b661a364160d0f05ea663df9ed637792.jpg)
Fig. 2 : DL total effective field for Gd&lt;sub&gt;25&lt;/sub&gt;Fe&lt;sub&gt;65.6&lt;/sub&gt;Co&lt;sub&gt;9.4&lt;/sub&gt;(10nm)/Cu(6nm), Gd&lt;sub&gt;25&lt;/sub&gt;Fe&lt;sub&gt;65.6&lt;/sub&gt;Co&lt;sub&gt;9.4&lt;/sub&gt; (10nm)/Cu(6nm)/Ta(5nm), and Gd&lt;sub&gt;25&lt;/sub&gt;Fe&lt;sub&gt;65.6&lt;/sub&gt;Co&lt;sub&gt;9.4&lt;/sub&gt; (10nm)/Cu(6nm)/Pt(5nm) as a function of the current density in the GdFeCo layer. There is only a small H&lt;sub&gt;DL&lt;/sub&gt; in GdFeCo/Cu (orange line) in which the spin absorption in Cu is small. H&lt;sub&gt;DL&lt;/sub&gt; in GdFeCo/Cu/Pt (blue diamonds) and GdFeCo/Cu/Ta (violet stars) corresponds to the addition of the SHE contribution from Pt (Ta) to the self-torque enhanced by the spin absorption outside GdFeCo by the spin-sink Pt or Ta.
