Spin-orbit torque (SOT) is currently the subject of intense research activity due to its potential for switching storage elements in magnetic random access memory[1], generating microwave frequency spin wave auto-oscillations in spin Hall nano-oscillators (SHNOs)[2], and manipulating magnetic textures, e.g. skyrmions[3] in magnetic logic devices. Device operation is underpinned by the spin Hall effect, in which a spin current can be efficiently generated at the interface between a ferromagnetic metal (FM) and a current carrying heavy metal (HM) underlayer due to strong spin-orbit coupling in the HM. The spin current may then exert a SOT on the magnetization of the FM, exciting magnetization dynamics central to device function.&lt;br/&gt;&lt;br/&gt;A recent study of nano-contacted SHNOs[2] revealed a spatial dependence of the SOTs due to the current distribution within the HM of the device. Moreover, micron and sub-micron scale ferromagnetic elements are known to support non-uniform equilibrium states resulting from strong demagnetizing fields[4]. Since the in-plane (Slonczewski) spin-torque term of the Landau-Lifshitz equation of motion depends upon the relative local orientation of the magnetization and the injected spin polarization, the resulting SOT can be spatially dependent. At the same time the Oersted (Oe) field generated by the DC and RF currents (&lt;i&gt;I&lt;/i&gt;&lt;sub&gt;DC&lt;/sub&gt;, &lt;i&gt;I&lt;/i&gt;&lt;sub&gt;RF&lt;/sub&gt;) in the HM will also lead to a spatially dependent DC deflection and RF excitation of the magnetization respectively. Therefore, to explore the influence of non-uniform SOTs at the nanoscale, a spatially resolved probe of the resulting magnetization dynamics is required.&lt;br/&gt;&lt;br/&gt;In this work time-resolved scanning Kerr microscopy (TRSKM) was used to acquire spatiotemporally resolved SOT ferromagnetic resonance (FMR) spectra from an in-plane magnetized Co&lt;sub&gt;40&lt;/sub&gt;Fe&lt;sub&gt;40&lt;/sub&gt;B&lt;sub&gt;20&lt;/sub&gt;(2 nm) ellipse of size 2×0.8 μm&lt;sup&gt;2 &lt;/sup&gt;positioned at the centre of a Pt(6 nm) Hall cross[5]. DC and RF currents were combined using a bias tee and passed through the 2 μm wide Pt lead perpendicular to the long axis of the ellipse, such that the resulting spin polarisation (σ(&lt;i&gt;t&lt;/i&gt;)) and Oe-fields (&lt;i&gt;h&lt;/i&gt;(&lt;i&gt;t&lt;/i&gt;)) were parallel to the long axis of the ellipse, Figure 1(a). Preliminary time-resolved polar Kerr measurements in response to a broadband current pulse allowed the resonance frequency (~2.7 GHz) to be determined for an in-plane bias magnetic field (&lt;i&gt;H&lt;/i&gt;&lt;sub&gt;B&lt;/sub&gt;) of 200 Oe, while the time-resolved measurements at &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;B&lt;/sub&gt; = 200 Oe in response to an RF current with frequency (&lt;i&gt;f&lt;/i&gt;&lt;sub&gt;RF&lt;/sub&gt;) of 2.72 GHz allowed the time delay of node and antinodes of precession at resonance to be determined. Sweeping the magnetic field with the time delay set to a node or an antinode allowed the real or imaginary components of the dynamic susceptibility to be probed respectively. Time-resolved polar Kerr images, Figs. 1(b) and 1(c) revealed that the dynamics at resonance were quasi-uniform at the center of the ellipse, while weaker signal at the edge was consistent with the spatial resolution of ~400 nm. SOT-FMR spectra were therefore acquired from the center of the ellipse for a range of field angles &lt;i&gt;θ&lt;/i&gt;&lt;sub&gt;B&lt;/sub&gt; and &lt;i&gt;I&lt;/i&gt;&lt;sub&gt;DC&lt;/sub&gt;, while f&lt;sub&gt;RF&lt;/sub&gt; was set to 3.2 GHz so that the resonance field was well separated from the field at which switching of the equilibrium magnetization occurred.&lt;br/&gt;&lt;br/&gt;Optically-detected SOT-FMR spectra acquired with &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;B&lt;/sub&gt; applied along the HA (&lt;i&gt;θ&lt;/i&gt;&lt;sub&gt;B&lt;/sub&gt; = 90°), and &lt;i&gt;I&lt;/i&gt;&lt;sub&gt;DC&lt;/sub&gt; = 0 mA showed negligible influence of SOT, i.e. symmetric FMR peaks with respect to field with no broadening or narrowing when magnetized in opposite HA directions. A macrospin calculation reproduced the peaks and a damping parameter α of 0.03 was extracted, similar to the previously reported value for these devices[1]. The coefficient of the in-plane torque term (ST) was assumed to be zero in the HA calculations with &lt;i&gt;I&lt;/i&gt;&lt;sub&gt;DC&lt;/sub&gt; = 0 mA. The value of &lt;i&gt;I&lt;/i&gt;&lt;sub&gt;DC&lt;/sub&gt; was then increased from 1 mA to 10 mA and spectra measured with &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;B&lt;/sub&gt; along the HA, which again showed symmetric FMR peaks. However, when the bias field was applied 30° to either side of the HA, marked asymmetry in both amplitude and linewidth were observed, in addition to a combined one- and two-fold angular dependence of the resonance field due to the DC Oe-field and shape anisotropy respectively. For a particular field history, the linewidth exhibited a marked crossover from broad to narrow as &lt;i&gt;θ&lt;/i&gt;&lt;sub&gt;B &lt;/sub&gt;was changed from +30° to -30° from the HA. These observations were reproduced by the macrospin calculations, but failed to reproduce the linewidth narrowing/broadening for a single value of ST with α = 0.03, while a smaller value of α = 0.025 reproduced the linewidth of all FMR peaks with ST = (6.75±0.75)×10&lt;sup&gt;-7&lt;/sup&gt; Oe A&lt;sup&gt;-1&lt;/sup&gt; cm&lt;sup&gt;2 &lt;/sup&gt;.&lt;br/&gt;&lt;br/&gt;This work paves the way for spatially resolved characterization of SOT devices at the deep nanoscale, e.g. using near-field magneto-optical techniques[6,7], that is needed to achieve greater understanding of SOT-induced dynamics.

**References:**

[1] G. Mihajlović, O. Mosendz, L. Wan, &lt;i&gt;et al.&lt;/i&gt;, Applied Physics Letters, Vol. 109, p. 192404 (2016)&lt;br/&gt;[2] T. M. Spicer, P. S. Keatley, T. H. J. Loughran, &lt;i&gt;et al&lt;/i&gt;., Physical Review B, Vol. 98, p. 214438 (2018)&lt;br/&gt;[3] K. Zeissler, S. Finizio, C. Barton, &lt;i&gt;et al&lt;/i&gt;., Nature Communications, Vol. 11, p. 428 (2020)&lt;br/&gt;[4] P. S. Keatley, V. V. Kruglyak, A. Neudert, &lt;i&gt;et al&lt;/i&gt;., Physical Review B, Vol. 78, p. 214412 (2008)&lt;br/&gt;[5] P. S. Keatley, K. Chatzimpaloglou, T. Manago, &lt;i&gt;et al&lt;/i&gt;., Under Review, (2021)&lt;br/&gt;[6] J. Rudge, H. Xu, J. Kolthammer, &lt;i&gt;et al&lt;/i&gt;., Review of Scientific Instruments, Vol. 86, p. 023703 (2015)&lt;br/&gt;[7] P. S. Keatley, T. H. J. Loughran, E. Hendry, &lt;i&gt;et al&lt;/i&gt;. Review of Scientific Instruments, Vol. 88, p. 123708 (2017)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/052e2ed3c5ccd518ec85d0ba2cc6bb61.jpg)
(a) A reflectivity image of the device acquired using the TRSKM with the current, spin polarization, and Oe-field directions overlaid. The ellipse is centered within the dashed white region of interest, which defines the scan range in (b) and (c). (b) and (c) Polar Kerr images acquired at opposite antinodes of precession while the ellipse was at resonance in response to an RF current only. An in-plane bias field of ~200 Oe was applied perpendicular to the long, easy axis (EA) of the ellipse (&lt;i&gt;θ&lt;/i&gt;&lt;sub&gt;B&lt;/sub&gt; = 90°). The nominal outline of the 2×0.8 μm&lt;sup&gt;2&lt;/sup&gt; ellipse is shown by the overlaid dashed line.



INTERMAG 2021

 Optically Detected Spin-Orbit Torque Ferromagnetic Resonance in an In-Plane Magnetized Ellipse

INTERMAG 2021 Welcome Video




<figure class="video_container">
 <iframe src="https://screencast-o-matic.com/player/crflqFVnUpZ?v=6&ff=1&title=0&controls=1" width=640 height=360 frameborder="0" allowfullscreen="true"> </iframe>
</figure>

Want to buy a ticket?

Register for INTERMAG 2021 here

[![](https://assets.underline.io/uploads/markdown_image/1/image/17ce76e7960db633258024eef8d6da7f.png)](https://intermag.org/register)

Got your ticket, but still can’t access the event?

Contact us and our team will look into it.

Spin-orbit torque (SOT) is currently the subject of intense research activity due to its potential for switching storage elements in magnetic random access memory[1], generating microwave frequency spin wave auto-oscillations in spin Hall nano-oscillators (SHNOs)[2], and manipulating magnetic textures, e.g. skyrmions[3] in magnetic logic devices. Device operation is underpinned by the spin Hall effect, in which a spin current can be efficiently generated at the interface between a ferromagnetic metal (FM) and a current carrying heavy metal (HM) underlayer due to strong spin-orbit coupling in the HM. The spin current may then exert a SOT on the magnetization of the FM, exciting magnetization dynamics central to device function. A recent study of nano-contacted SHNOs[2] revealed a spatial dependence of the SOTs due to the current distribution within the HM of the device. Moreover, micron and sub-micron scale ferromagnetic elements are known to support non-uniform equilibrium states resulting from strong demagnetizing fields[4]. Since the in-plane (Slonczewski) spin-torque term of the Landau-Lifshitz equation of motion depends upon the relative local orientation of the magnetization and the injected spin polarization, the resulting SOT can be spatially dependent. At the same time the Oersted (Oe) field generated by the DC and RF currents (IDC, IRF) in the HM will also lead to a spatially dependent DC deflection and RF excitation of the magnetization respectively. Therefore, to explore the influence of non-uniform SOTs at the nanoscale, a spatially resolved probe of the resulting magnetization dynamics is required. In this work time-resolved scanning Kerr microscopy (TRSKM) was used to acquire spatiotemporally resolved SOT ferromagnetic resonance (FMR) spectra from an in-plane magnetized Co40Fe40B20(2 nm) ellipse of size 2×0.8 μm2 positioned at the centre of a Pt(6 nm) Hall cross[5]. DC and RF currents were combined using a bias tee and passed through the 2 μm wide Pt lead perpendicular to the long axis of the ellipse, such that the resulting spin polarisation (σ(t)) and Oe-fields (h(t)) were parallel to the long axis of the ellipse, Figure 1(a). Preliminary time-resolved polar Kerr measurements in response to a broadband current pulse allowed the resonance frequency (~2.7 GHz) to be determined for an in-plane bias magnetic field (HB) of 200 Oe, while the time-resolved measurements at HB = 200 Oe in response to an RF current with frequency (fRF) of 2.72 GHz allowed the time delay of node and antinodes of precession at resonance to be determined. Sweeping the magnetic field with the time delay set to a node or an antinode allowed the real or imaginary components of the dynamic susceptibility to be probed respectively. Time-resolved polar Kerr images, Figs. 1(b) and 1(c) revealed that the dynamics at resonance were quasi-uniform at the center of the ellipse, while weaker signal at the edge was consistent with the spatial resolution of ~400 nm. SOT-FMR spectra were therefore acquired from the center of the ellipse for a range of field angles θB and IDC, while fRF was set to 3.2 GHz so that the resonance field was well separated from the field at which switching of the equilibrium magnetization occurred. Optically-detected SOT-FMR spectra acquired with HB applied along the HA (θB = 90°), and IDC = 0 mA showed negligible influence of SOT, i.e. symmetric FMR peaks with respect to field with no broadening or narrowing when magnetized in opposite HA directions. A macrospin calculation reproduced the peaks and a damping parameter α of 0.03 was extracted, similar to the previously reported value for these devices[1]. The coefficient of the in-plane torque term (ST) was assumed to be zero in the HA calculations with IDC = 0 mA. The value of IDC was then increased from 1 mA to 10 mA and spectra measured with HB along the HA, which again showed symmetric FMR peaks. However, when the bias field was applied 30° to either side of the HA, marked asymmetry in both amplitude and linewidth were observed, in addition to a combined one- and two-fold angular dependence of the resonance field due to the DC Oe-field and shape anisotropy respectively. For a particular field history, the linewidth exhibited a marked crossover from broad to narrow as θB was changed from +30° to -30° from the HA. These observations were reproduced by the macrospin calculations, but failed to reproduce the linewidth narrowing/broadening for a single value of ST with α = 0.03, while a smaller value of α = 0.025 reproduced the linewidth of all FMR peaks with ST = (6.75±0.75)×10-7 Oe A-1 cm2 . This work paves the way for spatially resolved characterization of SOT devices at the deep nanoscale, e.g. using near-field magneto-optical techniques[6,7], that is needed to achieve greater understanding of SOT-induced dynamics.

**References:**

[1] G. Mihajlović, O. Mosendz, L. Wan, et al., Applied Physics Letters, Vol. 109, p. 192404 (2016) [2] T. M. Spicer, P. S. Keatley, T. H. J. Loughran, et al., Physical Review B, Vol. 98, p. 214438 (2018) [3] K. Zeissler, S. Finizio, C. Barton, et al., Nature Communications, Vol. 11, p. 428 (2020) [4] P. S. Keatley, V. V. Kruglyak, A. Neudert, et al., Physical Review B, Vol. 78, p. 214412 (2008) [5] P. S. Keatley, K. Chatzimpaloglou, T. Manago, et al., Under Review, (2021) [6] J. Rudge, H. Xu, J. Kolthammer, et al., Review of Scientific Instruments, Vol. 86, p. 023703 (2015) [7] P. S. Keatley, T. H. J. Loughran, E. Hendry, et al. Review of Scientific Instruments, Vol. 88, p. 123708 (2017)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/052e2ed3c5ccd518ec85d0ba2cc6bb61.jpg)
(a) A reflectivity image of the device acquired using the TRSKM with the current, spin polarization, and Oe-field directions overlaid. The ellipse is centered within the dashed white region of interest, which defines the scan range in (b) and (c). (b) and (c) Polar Kerr images acquired at opposite antinodes of precession while the ellipse was at resonance in response to an RF current only. An in-plane bias field of ~200 Oe was applied perpendicular to the long, easy axis (EA) of the ellipse (θB = 90°). The nominal outline of the 2×0.8 μm2 ellipse is shown by the overlaid dashed line.

technical paper

I. Intorduction In this paper, a new coupling method for efficient and simple analysis of induction motor is presented. The circuit concept is applied to stator winding and each conductor loop of rotor composed of rotor bar and end ring segment. The flux linkage by magnetic field distribution is used instead of inductance matrix. The flux linkage is calculated using air-gap flux density distributions by unit current in stator winding and rotor bars. Once the field distribution by one coil is calculated by FEM, its result is used for total flux linkage by employing a coordinate transformation. Its numerical results show a good agreement with the existing results. Especially the method is very effective in analyzing the effect of the number of rotor bars. This This method can be used for the analysis of both three-phase induction motors and single-phase induction motors. As the classical theory for operating characteristics of induction motor, there are two main theories: the two-motor theory of two rotating fields and the cross field theory. But they cannot deal the coil distribution and accurate magnetic field distribution, so that the effects of the number of rotor bars is not characterized. On the other hand, its full finite element analysis requires massive calculation time and complex modeling techniques for time-stepping eddy current problem and remeshing problem. In this paper, the circuit concept is applied to the stator winding and the rotor conductor loops composed of rotor bar and end ring segment. The flux linkage obtained from FE field analysis is employed instead of inductance matrix. The flux linkage is calculated using the air gap field distribution by a unit current in stator and rotor bars. The total flux linkage of external circuit equation is easily calculated using superposition of each coil field and a coordinate transformation. That is, this method requires only few field analyses of a unit current of stator and rotor conductor. Once the flux parameters are obtained, the overall motor characteristics such as stator current, rotor bar current, torque are easily calculated in both transient state and steady state. The transient characteristics for the all currents are calculated in a recursive form by using finite time difference scheme. II. Coupling Method Circuit and Flux Distribution The circuit equation of stator winding is represented by convential voltage equation. The flux parameter of magnetic flux linkage is composed of the fields by both the stator winding current and the rotor bar currents. The circuit equation of rotor winding is also expressed by general equation like an Faraday's law. This Faraday formula requires a bar resistance, an endring resistance, and a current of each conductor bars. Also, the distribution of magnetic flux density on the rotor surface is required. Also, the KCL for the rotor bar and end ring is needed. Using the above equation we can calculate output current for the input voltage. The motor torque on the rotor bars can be also calculated from Lorentz force formula by using the resulting currents and magnetic flux density distribution. III. Numerical Applications The proposed algorithm is applied to a single and three phase induction motor. The rotor bar current is obtained as in Fig. 1. The average torque-speed curves according to different rotor bar resistances are shown in Fig. 2. This analysis technique is considered to be very useful to quickly grasp the characteristics in the initial process of designing single-phase and three-phase induction motors.

**References:**

[1] Gyril G. Veinott, E. E., D. Eng., Theory and Design of Small Induction Motors, McGRAW-HILL , 1959, pp. 184-197. [2] N. Sadowski, R. Carlson, S. R. Arruda, C. A. da Silva and M. Lajoic-Mazenc, “Simulation of Single-phase Induction Motor by a General Method Coupling Field and Circuit Equations,” IEEE Trans. on Magnetics, Vol. 31, No. 3, 1995. [3] Sheppard J. Salon, Finite Element Analysis of Electrical Machines, Kluwer Academic Publisher, 1995. [4]D. Kim and B. Kwon, "A Novel Equivalent Circuit Model of Linear Induction Motor Based on Finite Element Analysis and Its Coupling With External Circuits," in IEEE Transactions on Magnetics, vol. 42, no. 10, pp. 3407-3409, Oct. 2006. [5] M. Liu, K. W. Chan, J. Hu, Q. Lin, J. Liu and W. Xu, "Design and Realization of a Coreless and Magnetless Electric Motor Using Magnetic Resonant Coupling Technology," in IEEE Transactions on Energy Conversion, vol. 34, no. 3, pp. 1200-1212, Sept. 2019.

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/8f83bc771ba42b168160ed3ac845e9c8.jpg)
Fig. 1 Caculated Rotor Bar Current

![](https://assets.underline.io/uploads/markdown_image/1/image/725ae10d0e8c34dd2ac9ad472179abcb.jpg)
Fig. 2 Torque vs. Speed Characteristic Curve

 Coupling Method of Circuit Equation and Magnetic Field Distribution for Characterization of Induction Motors by Coordinate Transformation

INTRODUCTION Wireless power transfer (WPT) is increasingly popular in many interdisciplinary areas, such as energy encryption and electric vehicles [1]. As the WPT has unique advantages of higher flexibility and no sparking hazard [2], the WPT changes the conventional usage of energy in industry and domestic applications. Recently, a number of efforts have been made to incorporate WPT into electric motors to achieve wireless motor, which is favorable for harsh and watery environments. [3] can be regarded as a landmark paper for proposing dual controller wireless motor, which cascades the traditional motor system in the receiver side of WPT, thus wire abrasion can be avoided in harsh environments. However, motor controller is fragile and not suitable for isolated environments, so WPT with primary-control systems for DC motor [4], switched reluctance (SR) motor [2], and shaded pole induction motor (SPIM) [5] have been studied, which used self-drive circuit to replace the motor controller. However, DC motor suffers from the fragile carbon brushes and commutator, wireless SR motor needs three receivers, and wireless SPIM needs five controlled switches. To solve these problems, this paper proposed a new wireless system with secondary half-bridge inverter for SPIM, thus the number of controlled switches can be eliminated from five to two, and the key is to employ a three-winding transformer. METHODOLOGY Fig. 1 depicts the system configuration, where LT and LR are the inductance of transmitter and receiver, while CT, CT1, and LT1 are the resonant inductances and resonant capacitance to constitute the multiple-frequency resonating compensation (MFRC) network [6] at the transmitter side, and CR, CR1, and LR1 constitute the receiver’s MFRC network; LP, CP, LN, and CN constitute the positive and negative LC tuning circuits, which are resonant at fP and fN, respectively; CL is the filter capacitance of the bridge rectifier; SP and SN comprise the half-bridge inverter to control two primary transmitter windings, namely, positive and negative windings, respectively, and ILP and ILN are used to represent the current of these two windings; VS, VCP, VCN, and VM are adopted to represent the voltage of AC source, CP, CN, and load motor, respectively. It should be mentioned that the switched-capacitor array is adopted in [5], but this compensation suffers from high voltage switching stress. Thus, a specially designed MFRC network is employed in this paper (the design method is detailed in [6]), which can seamlessly compensate the receiver and transmitter at two frequencies without any voltage stress. The working principle is almost the same as [5], as the whole control process can be separated into positive and negative half-cycles, and the control signal for SP and SP are extracted from VCP, VCN, respectively. Taking positive half-cycle as an example, when the primary side transmits the energy at fP, the receiver current mainly flows the positive LC tunning circuit, so VCP is high while VCN is almost zero, thus SP is on, and SN is off. Therefore, by transmitting at fP or fN in turns, the positive and negative windings of the transformer are fed in turns. As the two primary windings of the transformer are reversely winded, AC voltage can be induced in the secondary winding of the transformer. Circuit simulations are carried out to show the feasibility of the proposed system. It should be mentioned that the load motor is replaced by a 120 Ω resistor, which is the equivalent resistance of SPIM in [5], and the other parameters will be given in the full paper. The simulation results are presented in Fig. 2, which depicts the waveforms of power source VS and load voltage VM, as well as the inverter output current ILP and ILN at different speeds. It should be noted that the power source should be higher when transmitting at a higher frequency [5], i.e., fN, in this paper. Consistent with theory analysis, when the system frequency alternatively changes between fP and fN, ILP and ILN correspondingly change, and an AC voltage VM is induced in the secondary side of the transformer to feed the SPIM. Besides, when the system works at rated condition, i.e., the effective value of VM is 110 V, VS is 70 V and 97 V at positive and negative half-cycles, respectively; when the system works at 25 Hz, and the effective value of VM is 55 V, VS becomes 35 V and 50 V at positive and negative half-cycles, respectively. Thus, it can be calculated that VS/VM is around 0.64 and 0.91 at positive and negative half-cycles, respectively. In other words, both the frequency and voltage of the load can be proportionally controlled from the primary side, thus the speed regulation can be achieved. CONCLUSION This paper proposed a novel WPT system for SPIM with a self-drive half-bridge inverter. Compared with former research [5], less controlled switches are applied, thus the proposed system has higher stability and is more suitable for isolated environments. Besides, in order to compensate the transmitter and receiver at two frequencies, a proper MFRC network is employed, which successfully avoids the voltage switching stress. Finally, the simulation results are presented to show system's feasibility and the speed regulation ability, and the experiment will be given in the full paper.
