I. INTRODUCTION&lt;br/&gt;With the development of electric drive technology, all electric and hybrid control has been more and more used in aerospace, and the integrated electric engine fuel pump on the aircraft has many potential advantages: compared with the traditional system using mechanical drive pump, the fuel control system is lighter, smaller, simpler and more efficient. Therefore, the fuel pump motor also plays an important role in electric drive control. The existing dual-winding fault-tolerant permanent magnet machine (DWFT-PMM) is generally designed with a rated speed of 5000rpm, rated power of 10kW and rated torque of 20Nm, the cooling mode is air cooling [1]. In [1], the optimized DWFT-PMM owns the advantages of physics isolation, strong magnetic isolation, inhibiting the short circuit current, small cogging torque ripple and high fault tolerance by designing and optimizing the air gap surface shape and anti short-circuit reactance parameters. It is precisely because of these advantages that existing DWFT-PMM as a fuel pump motor has a broad application and the idea of continuing to optimize this motor is worthwhile. However, in practical application, due to the speed demand of aviation fuel pump motor reaching 6000rpm or even higher, the demand for power and torque is relatively reduced, and the cooling mode is changed from air cooling to oil cooling. This paper aims to optimize the parameters of the existing DWFT-PMM. To improve the performance of DWFT-PMM and make it successfully used in the aviation field, the design and optimization of aviation fuel pump motor based on DWFT-PMM are proposed and studied in this paper. Firstly, according to the design specifications, the design and performance optimization scheme of the fuel pump motor is proposed and finally determined. Then, to verify the performance of the motor, the comparative analyses of the DWFT-PMM are showed in simulation and experiment, and the finite element analysis (FEA) results are given in terms of the sizing and volume, electromagnetic torque, no-load back EMF in simulation and experiment, etc. Based on the design and optimization results, the prototype is manufactured, and the experimental results of loss analysis are given. Finally, the conclusion is drawn.&lt;br/&gt;II. DESIGN AND PERFORMANCE OPTIMIZATIONS&lt;br/&gt;Fig.1 shows the comparison of two-dimensional (2-D) model and three-dimensional (3-D) model of DWFT-PMM before and after optimization along with the optimized prototype. It is indicated from models in Fig. 1(a) that the inner and outer diameters of the stator and rotor are reduced to achieve the optimization goal. The optimization goal also includes reducing the peak value of no-load back EMF to increase the speed, the cooling mode changed from air cooling to oil cooling, and reducing the copper loss, iron loss and mechanical loss. Fig. 1(b) shows the prototypes before and after DWFT-PMM optimization.&lt;br/&gt;III. FINITE ELEMENT ANALYSIS VERIFICATION&lt;br/&gt;According to the design and optimization parameters, no-load back-EMF waveforms of DWFT-PMM are shown in Fig .2(a) before and after optimization. The electromagnetic torque waveforms of DWFT-PMM before and after optimization are shown in Fig. 2(b). More detailed simulated verification will be presented in the full paper.&lt;br/&gt;IV. EXPERIMENTAL VERIFICATION&lt;br/&gt;The no-load back-EMF waveforms in experiment are respectively shown in Fig. 2(c). The former is when DWFT-PMM is running at the 2000r/min, and the latter is when the optimized DWFT-PMM is running at the 5000r/min.&lt;br/&gt;V. CONCLUSION&lt;br/&gt;This paper presents and studies the comparison and analysis of DWFT-PMM. According to the actual requirements, the speed of the fuel pump motor is higher and the cooling mode is oil cooling. So, the flow chart of the design and performance optimization of the existing DWFT-PMM is established. Then, the size of the stator and rotor and the number of coil turns of the fuel pump motor are designed and optimized. The performance of the optimized DWFT-PMM is analyzed by FEM from the aspects of inductance, cogging torque ripple, no-load back EMF, short circuit current, electromagnetic torque, and loss. Finally, the simulated and experimental results show that the optimized DWFT-PMM has the advantages of higher speed, better heat dissipation, smaller size, higher reliability, and more practicability. More detailed theoretical analysis, simulated and experimental verification will be presented in the full paper.&lt;br/&gt;ACKNOWLEDGMENT&lt;br/&gt;This work was supported in part by the National Natural Science Foundation of China under Project 51807094, and in part by the Project funded by China Postdoctoral Science Foundation under Project 2020M671499, and in part by High-level Innovative Entrepreneurial Talent Introduction Program of Jiangsu Province under Project [2019]20, and in part by Jiangsu Planned Projects for Postdoctoral Research Funds under Grant 2020Z145.

**References:**

[1] Xuefeng Jiang, Shaoshuai Wang, Qiang Li, Yufei Gao, “Design and optimization of dual-winding fault-tolerant permanent magnet motor,” CES Transactions on Electrical Machines and Systems, vol.3, no.1, pp.45- 53, (2019).

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/f2da28df7f90375fba2fec3189951abf.jpg)
Fig. 1. The proposed DWFTPMM. (a) Comparisons the 2-D of and the 3-D model. (b) Comparison of prototype.

![](https://assets.underline.io/uploads/markdown_image/1/image/bd64d249f73840e196d7baa6603ec893.jpg)
Fig. 2. Simulation and experimental comparison results of DWFT-PMM before and after optimization. (a) The comparison of no-load back EMF in simulation. (b) The comparison of the electromagnetic torque in simulation. (c) The comparison of no-load back EMF in experiment.

INTERMAG 2021

 Comparison and Analysis of Dual-Winding Fault-Tolerant Permanent Magnet Motor for Aviation Fuel Pump Applications

INTERMAG 2021 Welcome Video




<figure class="video_container">
 <iframe src="https://screencast-o-matic.com/player/crflqFVnUpZ?v=6&ff=1&title=0&controls=1" width=640 height=360 frameborder="0" allowfullscreen="true"> </iframe>
</figure>

Want to buy a ticket?

Register for INTERMAG 2021 here

[![](https://assets.underline.io/uploads/markdown_image/1/image/17ce76e7960db633258024eef8d6da7f.png)](https://intermag.org/register)

Got your ticket, but still can’t access the event?

Contact us and our team will look into it.

I. INTRODUCTION With the development of electric drive technology, all electric and hybrid control has been more and more used in aerospace, and the integrated electric engine fuel pump on the aircraft has many potential advantages: compared with the traditional system using mechanical drive pump, the fuel control system is lighter, smaller, simpler and more efficient. Therefore, the fuel pump motor also plays an important role in electric drive control. The existing dual-winding fault-tolerant permanent magnet machine (DWFT-PMM) is generally designed with a rated speed of 5000rpm, rated power of 10kW and rated torque of 20Nm, the cooling mode is air cooling [1]. In [1], the optimized DWFT-PMM owns the advantages of physics isolation, strong magnetic isolation, inhibiting the short circuit current, small cogging torque ripple and high fault tolerance by designing and optimizing the air gap surface shape and anti short-circuit reactance parameters. It is precisely because of these advantages that existing DWFT-PMM as a fuel pump motor has a broad application and the idea of continuing to optimize this motor is worthwhile. However, in practical application, due to the speed demand of aviation fuel pump motor reaching 6000rpm or even higher, the demand for power and torque is relatively reduced, and the cooling mode is changed from air cooling to oil cooling. This paper aims to optimize the parameters of the existing DWFT-PMM. To improve the performance of DWFT-PMM and make it successfully used in the aviation field, the design and optimization of aviation fuel pump motor based on DWFT-PMM are proposed and studied in this paper. Firstly, according to the design specifications, the design and performance optimization scheme of the fuel pump motor is proposed and finally determined. Then, to verify the performance of the motor, the comparative analyses of the DWFT-PMM are showed in simulation and experiment, and the finite element analysis (FEA) results are given in terms of the sizing and volume, electromagnetic torque, no-load back EMF in simulation and experiment, etc. Based on the design and optimization results, the prototype is manufactured, and the experimental results of loss analysis are given. Finally, the conclusion is drawn. II. DESIGN AND PERFORMANCE OPTIMIZATIONS Fig.1 shows the comparison of two-dimensional (2-D) model and three-dimensional (3-D) model of DWFT-PMM before and after optimization along with the optimized prototype. It is indicated from models in Fig. 1(a) that the inner and outer diameters of the stator and rotor are reduced to achieve the optimization goal. The optimization goal also includes reducing the peak value of no-load back EMF to increase the speed, the cooling mode changed from air cooling to oil cooling, and reducing the copper loss, iron loss and mechanical loss. Fig. 1(b) shows the prototypes before and after DWFT-PMM optimization. III. FINITE ELEMENT ANALYSIS VERIFICATION According to the design and optimization parameters, no-load back-EMF waveforms of DWFT-PMM are shown in Fig .2(a) before and after optimization. The electromagnetic torque waveforms of DWFT-PMM before and after optimization are shown in Fig. 2(b). More detailed simulated verification will be presented in the full paper. IV. EXPERIMENTAL VERIFICATION The no-load back-EMF waveforms in experiment are respectively shown in Fig. 2(c). The former is when DWFT-PMM is running at the 2000r/min, and the latter is when the optimized DWFT-PMM is running at the 5000r/min. V. CONCLUSION This paper presents and studies the comparison and analysis of DWFT-PMM. According to the actual requirements, the speed of the fuel pump motor is higher and the cooling mode is oil cooling. So, the flow chart of the design and performance optimization of the existing DWFT-PMM is established. Then, the size of the stator and rotor and the number of coil turns of the fuel pump motor are designed and optimized. The performance of the optimized DWFT-PMM is analyzed by FEM from the aspects of inductance, cogging torque ripple, no-load back EMF, short circuit current, electromagnetic torque, and loss. Finally, the simulated and experimental results show that the optimized DWFT-PMM has the advantages of higher speed, better heat dissipation, smaller size, higher reliability, and more practicability. More detailed theoretical analysis, simulated and experimental verification will be presented in the full paper. ACKNOWLEDGMENT This work was supported in part by the National Natural Science Foundation of China under Project 51807094, and in part by the Project funded by China Postdoctoral Science Foundation under Project 2020M671499, and in part by High-level Innovative Entrepreneurial Talent Introduction Program of Jiangsu Province under Project [2019]20, and in part by Jiangsu Planned Projects for Postdoctoral Research Funds under Grant 2020Z145.

**References:**

[1] Xuefeng Jiang, Shaoshuai Wang, Qiang Li, Yufei Gao, “Design and optimization of dual-winding fault-tolerant permanent magnet motor,” CES Transactions on Electrical Machines and Systems, vol.3, no.1, pp.45- 53, (2019).

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/f2da28df7f90375fba2fec3189951abf.jpg)
Fig. 1. The proposed DWFTPMM. (a) Comparisons the 2-D of and the 3-D model. (b) Comparison of prototype.

![](https://assets.underline.io/uploads/markdown_image/1/image/bd64d249f73840e196d7baa6603ec893.jpg)
Fig. 2. Simulation and experimental comparison results of DWFT-PMM before and after optimization. (a) The comparison of no-load back EMF in simulation. (b) The comparison of the electromagnetic torque in simulation. (c) The comparison of no-load back EMF in experiment.
