The Interior Permanent Magnet Synchronous Motor (IPMSM) is mainly used as a driving motor for Electric Vehicles (EVs) due to its advantage for high-power density and wide speed operation range. Because of the characteristics of EVs motor, it is necessary to perform high-speed driving at a small load condition. Thus, IPMSM is controlled by the field weakening control method to meet a wide operation range, which controls the phase angle through the d- and q-axis transformation. However, as the phase angle increases, the air-gap magnetic flux contains more harmonics and thus becomes less controllable, which has the drawback that there is a limit to the operation range. Moreover, in the case of large commercial EVs, high torque is required at low speed for the driving stability and the gradeability. Thus, to perform high torque at low speed, the motor should have a large permanent magnet in the motor. As the field magnetic flux increases, the back EMF also increases, so a larger phase angle is required for high-speed operation. However, the maximum speed that can be driven through the field weakening control is decreased because of the harmonics. For high-speed driving of commercial EVs, an optimal design method is needed to expand the field weakening region. The reason why the existence of a maximum speed limit is the increased harmonic component as the phase angle increases. In this paper, we divided the design part into the rotor and the stator. And then the effect on the field weakening control is analyzed when the design variables are changed. Finally, a motor design method for high-power at low-speed mode with a wide operation range is proposed by reducing harmonics and enhancing the back EMF controllability.&lt;br/&gt;To analyze the effects of the harmonics and the field weakening control characteristics as the design variable changed, no-load analysis is performed according to the number of slots per phase per pole. In the load analysis, the variation of line voltage is analyzed according to the current value when the maximum demagnetizing magnetomotive force is applied. Fig.1 represents that the larger the number of slots per phase per pole, the more stable voltage can be controlled. Namely, the voltage can be decreased by varying the current value and phase angle at a specific speed. It means that the limitation of the field weakening region can be possible calculated. Next, the field weakening control characteristic is analyzed according to the variation of the number of conductors per slot. Although the number of conductors per slot can reduce copper loss, it needs to prepare the countermeasure against voltage rising for field weakening control. To compare the effect according to the number of conductors in the field weakening region, the voltage values according to the number of turns are analyzed under the condition given the maximum demagnetizing magnetomotive force. The maximum operating speed considering the voltage limitation is selected. In consequence, fewer conductors in the slot are more advantageous for high-speed operation, but the rising current for voltage control and torque generation must be considered.&lt;br/&gt;The characteristic of field weakening control is analyzed by changing the magnet layer and shape, and the harmonic reduction analysis is implemented by the skewed method.&lt;br/&gt;Prior to the design of permanent magnet shape, permanent magnet with multi-layer structures, the air-gap magnetic flux is relatively sinusoidal compared to the single-layer. Moreover, the torque generation is flexible by securing the q-axis flux path. In other words, the multi-layer structure is used despite the difficulties of productivity due to this advantage. It is analyzed how the multi-layer structure affects the field weakening region.&lt;br/&gt;Additionally, the Total Harmonics Distortion (THD) and reluctance torque are analyzed according to changes in the number of magnet layers. As a result, the higher the number of layers, the lower the THD and the greater the proportion of the use of reluctance torque. It is indicated that the voltage controllability in the field weakening control range is more effective if the rotor flux linkage is small when the maximum demagnetizing magnetomotive force is applied.&lt;br/&gt;Depending on the shape of the permanent magnet, the barrier changes simultaneously, and the d- and q-axis flux path also changes. So, the air gap magnetic field distribution and voltage control performance are changed. The performance of voltage controllability according to the shape of the magnet is compared by representing the magnetic flux density in the air gap. In Fig.2, if the flux linkage is small, the voltage controllability in the field weakening control region is more stable when the maximum demagnetizing magnetomotive force is applied. As a result, V-type models demonstrate effectively reducing total flux linkage over Bar type models. Lastly, the skew is applied for optimized design to reduce harmonics. The lowest voltage curve can be investigated in both the skew and the non-skew models for comparison of harmonic reduction using FFT analysis.&lt;br/&gt;In this paper, with the main aim of optimizing the characteristics in the field weakening control region and improving the voltage control performance, the design of a motor for driving 300kW commercial EVs with a wide range of field weakening control region is presented.

**References:**

[1]Ki-Chan Kim, &quot;A Novel Magnetic Flux Weakening Method of Permanent Magnet Synchronous Motor for Electric Vehicles&quot;, IEEE Transactions on Magnetics, Vol.48, No.11, p.4042-4045 (2012)&lt;br/&gt;[2]J. A. Guemes, A. M. Iraolagoitia, and P. Fernandez, “Torque Analysis in Permanent-Magnet Synchronous Motors: A Comparative Study”, IEEE Transactions on Energy Conversion, Vol.26, No.1 p.55-63 (2011)&lt;br/&gt;[3]Jung-Min Mun, Yong-Jae Kim, and Sang-Yong Jung, &quot;Design Characteristics of IPMSM With Wide Constant Power Speed Range for EV Traction”, IEEE Transactions on Magnetics, Vol. 53, No.6 (2017)&lt;br/&gt;[4]Mohammad Sedigh Toulabi, John Salmon, and Andrew M. Knight, “Concentrated Winding IPM Synchronous Motor Design for Wide Field Weakening Applications”, IEEE Transactions on Industry Application, Vol.53, No.3 p.1892-1900 (2017)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/cb8f3fa65f04b2fffc98850c049c66f4.jpg)
Comparison of the lowest line voltage with different number of slots

![](https://assets.underline.io/uploads/markdown_image/1/image/bd596c5eb22c3a03064e9bf2ac8f85b6.jpg)
The comparison of the total flux linkage between 2-layers V-type and Bar-type model

INTERMAG 2021

 A Design of IPMSM High-Power Electric Vehicles with Wide Field Weakening Control Region

INTERMAG 2021 Welcome Video




<figure class="video_container">
 <iframe src="https://screencast-o-matic.com/player/crflqFVnUpZ?v=6&ff=1&title=0&controls=1" width=640 height=360 frameborder="0" allowfullscreen="true"> </iframe>
</figure>

Want to buy a ticket?

Register for INTERMAG 2021 here

[![](https://assets.underline.io/uploads/markdown_image/1/image/17ce76e7960db633258024eef8d6da7f.png)](https://intermag.org/register)

Got your ticket, but still can’t access the event?

Contact us and our team will look into it.

The Interior Permanent Magnet Synchronous Motor (IPMSM) is mainly used as a driving motor for Electric Vehicles (EVs) due to its advantage for high-power density and wide speed operation range. Because of the characteristics of EVs motor, it is necessary to perform high-speed driving at a small load condition. Thus, IPMSM is controlled by the field weakening control method to meet a wide operation range, which controls the phase angle through the d- and q-axis transformation. However, as the phase angle increases, the air-gap magnetic flux contains more harmonics and thus becomes less controllable, which has the drawback that there is a limit to the operation range. Moreover, in the case of large commercial EVs, high torque is required at low speed for the driving stability and the gradeability. Thus, to perform high torque at low speed, the motor should have a large permanent magnet in the motor. As the field magnetic flux increases, the back EMF also increases, so a larger phase angle is required for high-speed operation. However, the maximum speed that can be driven through the field weakening control is decreased because of the harmonics. For high-speed driving of commercial EVs, an optimal design method is needed to expand the field weakening region. The reason why the existence of a maximum speed limit is the increased harmonic component as the phase angle increases. In this paper, we divided the design part into the rotor and the stator. And then the effect on the field weakening control is analyzed when the design variables are changed. Finally, a motor design method for high-power at low-speed mode with a wide operation range is proposed by reducing harmonics and enhancing the back EMF controllability. To analyze the effects of the harmonics and the field weakening control characteristics as the design variable changed, no-load analysis is performed according to the number of slots per phase per pole. In the load analysis, the variation of line voltage is analyzed according to the current value when the maximum demagnetizing magnetomotive force is applied. Fig.1 represents that the larger the number of slots per phase per pole, the more stable voltage can be controlled. Namely, the voltage can be decreased by varying the current value and phase angle at a specific speed. It means that the limitation of the field weakening region can be possible calculated. Next, the field weakening control characteristic is analyzed according to the variation of the number of conductors per slot. Although the number of conductors per slot can reduce copper loss, it needs to prepare the countermeasure against voltage rising for field weakening control. To compare the effect according to the number of conductors in the field weakening region, the voltage values according to the number of turns are analyzed under the condition given the maximum demagnetizing magnetomotive force. The maximum operating speed considering the voltage limitation is selected. In consequence, fewer conductors in the slot are more advantageous for high-speed operation, but the rising current for voltage control and torque generation must be considered. The characteristic of field weakening control is analyzed by changing the magnet layer and shape, and the harmonic reduction analysis is implemented by the skewed method. Prior to the design of permanent magnet shape, permanent magnet with multi-layer structures, the air-gap magnetic flux is relatively sinusoidal compared to the single-layer. Moreover, the torque generation is flexible by securing the q-axis flux path. In other words, the multi-layer structure is used despite the difficulties of productivity due to this advantage. It is analyzed how the multi-layer structure affects the field weakening region. Additionally, the Total Harmonics Distortion (THD) and reluctance torque are analyzed according to changes in the number of magnet layers. As a result, the higher the number of layers, the lower the THD and the greater the proportion of the use of reluctance torque. It is indicated that the voltage controllability in the field weakening control range is more effective if the rotor flux linkage is small when the maximum demagnetizing magnetomotive force is applied. Depending on the shape of the permanent magnet, the barrier changes simultaneously, and the d- and q-axis flux path also changes. So, the air gap magnetic field distribution and voltage control performance are changed. The performance of voltage controllability according to the shape of the magnet is compared by representing the magnetic flux density in the air gap. In Fig.2, if the flux linkage is small, the voltage controllability in the field weakening control region is more stable when the maximum demagnetizing magnetomotive force is applied. As a result, V-type models demonstrate effectively reducing total flux linkage over Bar type models. Lastly, the skew is applied for optimized design to reduce harmonics. The lowest voltage curve can be investigated in both the skew and the non-skew models for comparison of harmonic reduction using FFT analysis. In this paper, with the main aim of optimizing the characteristics in the field weakening control region and improving the voltage control performance, the design of a motor for driving 300kW commercial EVs with a wide range of field weakening control region is presented.

**References:**

[1]Ki-Chan Kim, "A Novel Magnetic Flux Weakening Method of Permanent Magnet Synchronous Motor for Electric Vehicles", IEEE Transactions on Magnetics, Vol.48, No.11, p.4042-4045 (2012) [2]J. A. Guemes, A. M. Iraolagoitia, and P. Fernandez, “Torque Analysis in Permanent-Magnet Synchronous Motors: A Comparative Study”, IEEE Transactions on Energy Conversion, Vol.26, No.1 p.55-63 (2011) [3]Jung-Min Mun, Yong-Jae Kim, and Sang-Yong Jung, "Design Characteristics of IPMSM With Wide Constant Power Speed Range for EV Traction”, IEEE Transactions on Magnetics, Vol. 53, No.6 (2017) [4]Mohammad Sedigh Toulabi, John Salmon, and Andrew M. Knight, “Concentrated Winding IPM Synchronous Motor Design for Wide Field Weakening Applications”, IEEE Transactions on Industry Application, Vol.53, No.3 p.1892-1900 (2017)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/cb8f3fa65f04b2fffc98850c049c66f4.jpg)
Comparison of the lowest line voltage with different number of slots

![](https://assets.underline.io/uploads/markdown_image/1/image/bd596c5eb22c3a03064e9bf2ac8f85b6.jpg)
The comparison of the total flux linkage between 2-layers V-type and Bar-type model

poster

I. Introduction Variable flux memory machines (VFMM) equipped with low coercive force (LCF) aluminum-nickel-cobalt (AlNiCo) magnets [1]-[4] can achieve high efficiency over a wide operation range by applying a current pulse to magnetize the LCF magnets with negeligible copper loss. Thus, VFMM is widely recognized as a competitive candidate for traction applications. For elevating the the electromagnetic performance of VFMMs, hybrid usage of high coercive force (HCF) and LCF magnets are applied in VFMMs. A novel hybrid-magnet-circuit VFMM (HMC-VFMM) is proposed in [5], which combines the design concepts and strengths of VFMMs with parallel and series magnetic circuit of HCF and LCF magnets. Due to the special hybrid magnetic circuit design, it is essential to provide an insightful understanding about the nonlinear hysteresis behavior of the LCF working point considering the resultant effects of parallel and series branches and to analyze the magnetic field variation phenomenon of the developed HMC-VFMM due to the transient current pulse by an effective solution. This paper attempts to reveal and investigate a balanced bidirectional-magnetization effect of the proposed HMC-VFMM, i.e., the required demagnetizing and remagnetizing current levels are basically similar, which will benefit the inverter rating reduction and online flux control. The balanced bidirectional-magnetization effect is analytically revealed by using a simplified Fourier-series based hysteresis model. In addition, the numerical hysteresis model is programmed with FE model so as to accurately investigate the magnetization characteristics of HMC-VFMM. Finally, the experimental results on a prototype are carried out to verify the theoretical analyses. II. Machine configuration and working principle The proposed 21-slot/4-pole HMC-VFMM is investigated, in which the cross-section is illustrated in Figs. 1(a). The proposed HMC design is characterized by a dual-layer PM structure. For the parallel branch, the “U”-shaped hybrid PM arrangement is employed. For the series branch, the HCF PMs form a spoke-type flux concentration type. The proposed HMC-VFMM can combine the advantages of wide flux regulation range in parallel type and excellent on-load demagnetization withstand capability in series type. The variable-flux principle of the proposed HMC-VFMM can be illustrated by the open-circuit field distributions under different magnetization states (MSs) in Fig. 1(b). It can be observed that the air-gap flux can be flexibly adjusted by applying a transient magnetizing or demagnetizing current pulse. Meanwhile, due to the variable flux property, the losses at different speeds and loads can be also manipulated to realize efficiency improvement over a wide operating range. III. Analytical Analysis of Balanced Bidirectional-Magnetization Effect The nonlinear hysteresis characteristics of the LCF PMs used in the proposed HMC-VFMM can be characterized by a simple Fourier-series based hysteresis model as shown in Fig. 2(a). The PM working point can track along different recoil lines by applying a specific remagnetizing or demagnetizing current pulse. The underlying mechanism of the balanced bidirectional-magnetization effect can be physically characterized by hysteresis curves of the LCF PM in Fig. 2(b). The load line of the HMC design is placed between the two load lines of the parallel and series cases, which allows a better balance between the magnetizing and demagnetizing current amplitudes. Meanwhile, the oversized inverter rating issue for either parallel or series VFMMs can be well avoided by appropriately reducing maximum remagnetizing currents. The detailed analysis and investigation of magnetization characteristics of HMC-VFMM will be given in the full paper.

**References:**

[1] V. Ostovic, "Memory Motors," IEEE Ind. Appl. Mag., vol. 9, no. 1, pp. 52-61, Jan./Feb. 2003. [2] H. Liu, H. Lin, Z. Q. Zhu, M. Huang, and P. Jin, "Permanent Magnet Remagnetizing Physics of a Variable Flux Memory Motor," IEEE Trans. Magn., vol. 46, no. 6, pp. 1679-1682, 2010. [3] Yu, C. and K. T. Chau . "Design, Analysis, and Control of DC-Excited Memory Motors," IEEE Trans. Energy Convers., vol. 26, no. 2, pp.479-489, 2011. [4] N. Limsuwan, T. Kato, K. Akatsu, and R. D. Lorenz, "Design and Evaluation of a Variable-Flux Flux-Intensifying Interior Permanent-Magnet Machine," IEEE Trans. Ind. Appl., vol. 50, no. 2, 2014. [5] H. Yang, S. Lyu, H. Lin, Z. Q. Zhu, H. Zheng and T. Wang, "A novel hybrid-magnetic-circuit variable flux memory machine," IEEE Trans. Ind. Electron., vol. 67, no. 7, pp. 5258-5268, 2020.

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/fd15041edf173bd5308f52185a96915d.jpg)
Fig. 1 VFMM topology and open-circuit field distributions under different magnetization states. (a) Topology. (b) Open-circuit field distributions under different magnetization states.

![](https://assets.underline.io/uploads/markdown_image/1/image/c7f4e39097f597c7fe82679fc137ef9c.jpg)
Fig. 2 Illustration of Fourier-series based hysteresis model. (a) Simplified view for illustrating the variable flux principle. (b) Numerical representation.

 Investigation of Balanced Bidirectional-Magnetization Effect of a Novel Hybrid-Magnet-Circuit Variable Flux Memory Machine
