I. INTRODUCTION&lt;br/&gt;Magnetoencephalographs (MEGs) require a magnetically shielded room (MSR) made of mu-metal to protect against very slow and small range of magnetic field (micromagnetic field) noise. As magnetic shields tend to be very expensive, the evaluation of the magnetic shielding factor &lt;i&gt;SF&lt;/i&gt; of the MSR in advance is crucial. The permeability &lt;i&gt;μ&lt;/i&gt; of the shielding material is the main factor affecting the magnetic properties, which influence the &lt;i&gt;SF&lt;/i&gt;. Conventionally, an index of permeability at &lt;i&gt;H&lt;/i&gt; = 4 mA/cm, which we denote as “μ&lt;sub&gt;4&lt;/sub&gt;” in this paper, is used to evaluate the performance of a mu-metal. However, as we explained in a previous study [1], permeability at a lower range than 4 mA/m, such as the Rayleigh region [2], is important for magnetic shielding materials in MSRs used for MEGs. We also explained that the measurement system of permeability against a very low-frequency micromagnetic field fluctuation and heat treatment process can improve the permeabilities of a mu-metal [3]. The &lt;i&gt;SF&lt;/i&gt; is also affected by the shape of the magnetic shield. As a first step for predicting the &lt;i&gt;SF&lt;/i&gt; of an MSR model, we examined a cylindrical-shell magnetic shield (material thickness, &lt;i&gt;t&lt;/i&gt; = 1 mm; length, &lt;i&gt;L&lt;/i&gt; = 640 mm; diameter, &lt;i&gt;D&lt;/i&gt; = 100 mm), which can be considered as infinitely long and can be applied with &lt;i&gt;SF&lt;/i&gt; = 1+&lt;i&gt;µt&lt;/i&gt;/&lt;i&gt;D&lt;/i&gt; [4]. We propose a prediction method for the &lt;i&gt;SF&lt;/i&gt; by using this formula and the estimated &lt;i&gt;μ&lt;/i&gt;. The permeability index, &lt;i&gt;μ&lt;/i&gt;, of a ring-shaped test piece (ring TP) was measured at a magnetic field strength of 0.001–0.675 A/m, which comprises the linear region in the &lt;i&gt;μ&lt;/i&gt;–&lt;i&gt;H&lt;/i&gt; curve, to detect the initial permeability, μ&lt;sub&gt;i&lt;/sub&gt;, and Rayleigh constant &lt;i&gt;ν&lt;/i&gt;; Rayleigh’s law states the &lt;i&gt;μ&lt;/i&gt;–&lt;i&gt;H&lt;/i&gt; curve is present for &lt;i&gt;μ&lt;/i&gt; = μ&lt;sub&gt;i&lt;/sub&gt; + &lt;i&gt;νH&lt;/i&gt;. Before we apply two equations to calculate &lt;i&gt;SF&lt;/i&gt;, we need to know the internal magnetic field of the material &lt;i&gt;H &lt;/i&gt;= &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;i&lt;/sub&gt;, whose value is attenuated from applied magnetic field &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;e&lt;/sub&gt; due to the demagnetization effect of its cylindrical-shell shape. Although the demagnetizing factors of spheres and ellipsoids are known, it is difficult to calculate these values for other shapes. Therefore, we used magnetic field analysis to estimate the internal magnetic field &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;i&lt;/sub&gt; of the cylindrical shell. In this study, a prediction method of the &lt;i&gt;SF&lt;/i&gt; for a cylindrical shell was demonstrated for three types of mu-metals, and its accuracy was verified by an experiment on the &lt;i&gt;SF&lt;/i&gt;.&lt;br/&gt;&lt;br/&gt;II. METHOD&lt;br/&gt;We prepared three types of mu-metals (mu-metals 1, 2, and 3), which exhibited different properties. A ring TP and cylindrical shell were fabricated from mu-metals 1, 2, and 3. The ring TPs and cylindrical shells were simultaneously magnetically annealed in the same heat-treatment furnace. The prediction of the &lt;i&gt;SF&lt;/i&gt;s was performed in three steps. First, ring TPs were measured in an alternating magnetic field of 1 Hz, and μi and &lt;i&gt;ν&lt;/i&gt; were obtained via the least-squares method that was applied to the &lt;i&gt;μ&lt;/i&gt; data of the linear region. Second, the &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;i&lt;/sub&gt; values of the cylindrical shells were estimated using magnetic simulation software ELF/MAGIC (ELF corporation). A cylindrical shell was modeled as a 3D object that was divided into 180 cells along its circumferential direction, 64 along the length, and using a single cell along the thickness. &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;i&lt;/sub&gt; was obtained as the average value of all dividing elements; &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;e&lt;/sub&gt; was varied as 0.01, 0.1, 1, and 10 A/m (0 to peak); and &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;i&lt;/sub&gt; was calculated for each level of &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;e&lt;/sub&gt;. Third, &lt;i&gt;SF&lt;/i&gt; was predicted as &lt;i&gt;SF&lt;/i&gt; = 1 + &lt;i&gt;µt&lt;/i&gt;/&lt;i&gt;D&lt;/i&gt; using the equation &lt;i&gt;μ &lt;/i&gt;= μ&lt;sub&gt;i&lt;/sub&gt; + &lt;i&gt;νH&lt;/i&gt;&lt;sub&gt;i&lt;/sub&gt;. Fourth, the cylindrical shells fabricated from mu-metals 1, 2, and 3 were placed in a uniform magnetic field strength of &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;e&lt;/sub&gt; that varied at 1 Hz, and the magnetic field at the center of the shell &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;p&lt;/sub&gt; was measured. The &lt;i&gt;SF&lt;/i&gt; was obtained as &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;e&lt;/sub&gt;/&lt;i&gt; H&lt;/i&gt;&lt;sub&gt;p&lt;/sub&gt; and compared with the predicted result.&lt;br/&gt;&lt;br/&gt;III. RESULT AND DISCUSSION&lt;br/&gt;The &lt;i&gt;μ&lt;/i&gt;–&lt;i&gt;H&lt;/i&gt; curve, μ&lt;sub&gt;i&lt;/sub&gt; and &lt;i&gt;ν&lt;/i&gt; of the ring TPs are displayed in Fig. 1. The internal magnetic fields &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;i&lt;/sub&gt; of the cylindrical shell calculated using the magnetic simulation software were 1/1608 to 1/418 of &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;e&lt;/sub&gt;, and were in the Rayleigh region. Fig. 2 shows the predicted &lt;i&gt;SF&lt;/i&gt; using &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;i&lt;/sub&gt; values of each &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;e&lt;/sub&gt; and the experimental results for the three types of cylindrical shells. It showed that mu-metal 3 has the highest &lt;i&gt;μ&lt;/i&gt; in the Rayleigh region, mu-metal 2 has the lowest &lt;i&gt;μ&lt;/i&gt;, and so as the order of the &lt;i&gt;SF&lt;/i&gt;. Both results of the prediction and experiment show the tendency that the SF increases with an increase in He, and are in good agreement.&lt;br/&gt;&lt;br/&gt;IV. CONCLUSION&lt;br/&gt;To develop an accurate prediction method for the magnetic shielding factor in the design of an MSR, we proposed a prediction method for cylinders as a preliminary step and verified its accuracy via the comparison with the result of the experiment. The value of &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;i&lt;/sub&gt; indicate that only few of &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;e&lt;/sub&gt; can penetrate inside the material of cylindrical shell, and thus &lt;i&gt;μ&lt;/i&gt; of micromagnetic field such as the Rayleigh region is important for a magnetic shield against even large magnetic field noise of 10 A/m. As shown in Fig. 2, it was confirmed that the value of &lt;i&gt;μ&lt;/i&gt; calculated using Rayleigh’s law is linked to the magnetic shielding effect, and the result also indicated the possibility of applying it to predict &lt;i&gt;SF&lt;/i&gt; of MSR.
