 Design and Optimization of New Flux-Concentrating Rotors combining Halbach PM array and spoke-type IPM for PMSM

The 15th Joint MMM-INTERMAG Conference (2022 Joint) is sponsored jointly by AIP Publishing and the IEEE Magnetics Society. Members of the international scientific and engineering communities interested in recent developments in fundamental and applied magnetism are invited to attend and contribute to the technical sessions. The technical program will include invited and contributed papers in oral and poster sessions, invited symposia, a plenary session, and an evening session, with about 1500 presentations overall. This Conference provides an outstanding opportunity for worldwide participants to meet their colleagues and collaborators and discuss developments in all areas of magnetism research.

The 2022 Joint Conference will offer both in-person and prerecorded on-demand content.

For tickets to the event, please register at the following link: https://magnetism.org/register

Please register for the Joint MMM-Intermag conference to join the event.

2022 Joint MMM-INTERMAG

This Conference provides an outstanding opportunity for worldwide participants to meet their colleagues and collaborators and discuss developments in all areas of magnetism research.

I. INTRODUCTION This paper proposed a new flux-concentrating rotor for PM machine, taking advantages of spoke-type and Halbach array PM flux-concentrating. As shown in Fig. 1 (a), it is the evolution of the proposed rotor. The upper part of tangentially magnetized magnets still remain the spoke-type flux-concentrating property, while the bottom tangentially magnetized magnets and the radially magnetized magnets form a primitive Halbach array [1] [2]. Since the ratio match tangentially/radially magnetized magnets directly affects the effect of flux-concentrating, as well as the saliency ratio and torque performance, this paper focuses on the optimization of the size of permanent magnets on the rotor on the basis of keeping the same amount of PMs and the polar arc coefficient. II. OPTIMAL DESIGN OF NEW FLUX-CONCENTRATING ROTOR Response surface method (RSM) is a set of statistical and mathematical techniques to find the “best fitted” response of the physical system through experiment or simulation [3]. In RSM, a polynomial model, called a fitted model, is generally constructed to represent the relationship between the performance and design parameters. As shown in Fig. 1 (a), it is the evolution of the proposed rotor. Ensuring the same volume of PM in three rotors, the new rotor was optimized. The geometric parameters of the new rotor are shown in Fig. 1 (b). In order to quantitatively compare with the motor whose pole-arc coefficient is 0.8, including in various electromagnetic characteristics. b is determined as 8 mm. The volume of PM is defined as (1). where p is pole pairs, l is stack length, m is the volume of PMs. The optimized objective is formulated to maximize the air-gap flux density under the constraint of keeping the PM volume. Tab. I shows electromagnetic analysis results under various combinations of lx and hy. The relationship between air-gap flux density and lx, hy is shown in Fig. 2 (a). Two optimized points are found, where the analysis result is better than the predicted value. The regression equations of air-gap flux density obtained by RSM analysis is as (2). As shown in Fig. 2 (b), the predicted value and the actual result maintain a high consistency. It can be concluded that the regression equation obtained by the RMS is reliable. As shown in Fig. 3, The result of optimization is to maximize the air-gap magnetic density. . lx is determined as 16.5 mm, and hy is determined as 3.75 mm. Fig. 4 shows the comparison of two rotors. The final optimized model is built by 2-D FEA, as shown in Fig.5. III. FEA AND EXPERIMENTAL VERIFICATION Tab. II gives the main parameters of optimized rotor. Fig. 6 (a) compares the air-gap flux density of the motors with optimized rotor and the original rotor. The air-gap flux density in the motor with optimized rotor is higher than that in the initial one. As shown in Fig. 6 (b), the line back electromotive force (EMF) of the motor with optimized rotor increases slightly due to the higher air gap flux density. Fig. 6 (c) shows the C-T relationship under maximum torque per ampere (MTPA) control and id=0 control. The results show that under MTPA control and id=0 control, the output torque of the optimized rotor is higher than the initial model. In Fig. 6 (d), the saliency ratio is higher in the optimized rotor than in the original one. so the flux-weakening ability is stronger. Considering the manufacturing process, the actual rotor structure is shown in Fig. 7 the shape of the radially magnetized PMs are rectangular. The stator, rotor and test platforms are shown in Fig. 8. Fig. 9 compares the experimental and FEA results. Fig. 9 (a) is the comparison between the experimental and analytical result about back EMF without load, Fig. 9 (b) shows the C-T relationship of the motors with original rotor and optimized rotor under MTPA control and the results present a high consistency and error is less than 2%. But the error is large in the relationship between experiment and analysis under id=0 control due to the reluctance torque is fully utilized with the large current. IV. CONCLUSION In this paper, a new flux-concentrating rotor for PM machines is designed to combing spoke-type IPM rotor and Halbach PM array The size parameters of PM of the new rotor are optimized by the response surface method for the maximum air-gap flux density and torque capacity considering the constant pole-arc coefficient and the volume of PM.The 72-slot/16-pole PM motor with the optimized rotor is developed by 2-D FEA and experiments. The experimental result the air-gap flux density is increased by 6.7%and the torque is increased by 7.5%.
