I. Introduction&lt;br/&gt;As a new type of elevator drive and load-bearing member, the composite steel belt has been used widely. Inside the composite steel belt, there are multiple small-diameter steel wire ropes side by side, and the rope spacing is small. The surface of these side-by-side wire ropes is covered with a special plastic material. So, the composite steel belt has large traction capability and high flexibility, which makes the main engine volume smaller than that of the traditional elevator product mainframe. Furthermore, the composite steel belt has more steel wires than the conventional wire rope, which is more durable and has a longer service life. In additional, the composite steel belt is lighter in weight, and it can effectively reduce the vibration and noise during the operation of the elevator. A number of elevator manufacturers are also gradually adopting and promoting the use of composite steel strips in elevators.&lt;br/&gt;However, the surface of the composite steel strip is covered with a wear-resistant plastic material such as polyurethane. In the process of use, if the internal steel wire rope has defects such as warping, breaking, misalignment, and thinning, it cannot be recognized by the naked eye, which affects the safety of the elevator. If the internal wire rope has potential defects at the time of leaving the factory, it is easy to scratch the surface rubber material, which is more likely to cause an accident. Therefore, the damage detection of the composite steel belt plays an important role in the safe operation of the elevator [1]. The rope in the composite steel belt belongs to ferromagnetic component, electromagnetic detection methods is ideal for its non-destructive testing [2]. In addition, the electromagnetic detection method has also been used for fine steel wire rope detection and achieved a good detection effect [3]. The wire ropes inside the composite steel belt are just fine steel wire ropes. Electromagnetic finite element simulation analysis (FEA) can provide magnetic field status reference for electromagnetic detection of wire rope [4]. The application of some magnetic dipole model analysis and related algorithms in electromagnetic detection also provides relevant references for the detection of wire rope defects[5,6].&lt;br/&gt;II. Simulation and Excitation Structure Design&lt;br/&gt;The schematic diagram of the common composite steel strip structure is shown in Fig. 1(a), and the excitation structure is established as shown in Fig. 1(b). By selecting the appropriate size of permanent magnet and yoke, the wire ropes in the composite steel belt are excited to near saturation.&lt;br/&gt;In the simulation, three defects appear on the first, fifth and ninth wire ropes at the same time. Extract the radial magnetic flux leakage directly above and below each wire rope and above and below both sides of the 1st and 10th wire ropes, as shown in Fig. 1(c) and Fig. 1(d). It can be seen that on the defective wire ropes, the radial magnetic flux leakage is large, and on the wire rope without defects, the magnetic flux leakage is very small. Therefore, magnetic detection sensors (such as hall, anisotropic magneto-resistive, giant magneto-resistive, fluxgate, tunnel magneto-resistive, etc.) can be arranged above and below each wire for picking up the magnetic flux leakage signal, thereby detecting the defect.&lt;br/&gt;III. Experimental and Results&lt;br/&gt;Since the diameter of the wire rope and the distance between the ropes inside the composite steel belt is small. The hall element having a small volume and high sensitivity is selected as the detecting sensor. The halls are placed above and below each wire rope. For the signal processing, the hall output signals above and below each wire are first summed up. Then the noise and interference signals are filtered out by a bandpass filter. Subsequent use of a comparator to determine the defect.&lt;br/&gt;Fig.2a) shows a photograph of a steel belt with three defects, each of which is located on a wire rope inside. Fig.2b) shows the design of the steel wire rope detection device inside the composite steel strip and the detection result when the second defect is detected.

**References:**

[1] H.M. Lei, G.Y. Tian, “Broken wire detection in coated steel belts using the magnetic flux leakage method,” &lt;i&gt;Insight&lt;/i&gt;, vol. 55, no. 3, pp.126-31, 2013.&lt;br/&gt;[2] H. R. Weischedel, R. P. Ramsey, “Electromagnetic testing, a reliable method for the inspection of wire ropes in service,” &lt;i&gt;NDT&amp;E Int.&lt;/i&gt;, vol. 22, no. 3, pp.155-161, 1989.&lt;br/&gt;[3] X. L. Yan, D. L. Zhang, and S. M. Pan, “Online nondestructive testing for fine steel wire rope in electromagnetic interference environment”, &lt;i&gt;NDT E Int&lt;/i&gt;., no. 92, pp. 75–81, 2017.&lt;br/&gt;[4] R. H. Priewald, C. Magele, and P. D. Ledger, et al. “Fast magnetic flux leakage signal inversion for the reconstruction of arbitrary defect profiles in steel using finite elements”. &lt;i&gt;IEEE Trans. Magn&lt;/i&gt;., vol. 9, no. 1, pp. 506-516, 2013.&lt;br/&gt;[5] Li E, Kang Y, Tang J. et al. “Analysis on Spatial Spectrum of Magnetic Flux Leakage Using Fourier Transform”. &lt;i&gt;IEEE Trans. Magn.&lt;/i&gt;, vol. 54, no. 8, pp. 6201810, 2018.&lt;br/&gt;[6] Hosseingholizadeh S, Filleter T, Sinclair A. “Evaluation of a Magnetic Dipole Model in a DC Magnetic Flux Leakage System”. &lt;i&gt;IEEE Trans. Magn.&lt;/i&gt;, vol. 55, no. 4, pp. 6200407, 2019.

**Images:**
![](https://assets.underline.io/uploads/markdown_image/1/image/71c400da15890673ef973c968b06563d.jpg)

![](https://assets.underline.io/uploads/markdown_image/1/image/245708bac6cfce5ff30346c106e13afb.jpg)





INTERMAG 2021

Electromagnetic Non-destructive Testing of Wire Rope Inside Composite Steel Belts

The 15th Joint MMM-INTERMAG Conference (2022 Joint) is sponsored jointly by AIP Publishing and the IEEE Magnetics Society. Members of the international scientific and engineering communities interested in recent developments in fundamental and applied magnetism are invited to attend and contribute to the technical sessions. The technical program will include invited and contributed papers in oral and poster sessions, invited symposia, a plenary session, and an evening session, with about 1500 presentations overall. This Conference provides an outstanding opportunity for worldwide participants to meet their colleagues and collaborators and discuss developments in all areas of magnetism research.

The 2022 Joint Conference will offer both in-person and prerecorded on-demand content.

For tickets to the event, please register at the following link: https://magnetism.org/register

Please register for the Joint MMM-Intermag conference to join the event.

2022 Joint MMM-INTERMAG

This Conference provides an outstanding opportunity for worldwide participants to meet their colleagues and collaborators and discuss developments in all areas of magnetism research.

I. Introduction As a new type of elevator drive and load-bearing member, the composite steel belt has been used widely. Inside the composite steel belt, there are multiple small-diameter steel wire ropes side by side, and the rope spacing is small. The surface of these side-by-side wire ropes is covered with a special plastic material. So, the composite steel belt has large traction capability and high flexibility, which makes the main engine volume smaller than that of the traditional elevator product mainframe. Furthermore, the composite steel belt has more steel wires than the conventional wire rope, which is more durable and has a longer service life. In additional, the composite steel belt is lighter in weight, and it can effectively reduce the vibration and noise during the operation of the elevator. A number of elevator manufacturers are also gradually adopting and promoting the use of composite steel strips in elevators. However, the surface of the composite steel strip is covered with a wear-resistant plastic material such as polyurethane. In the process of use, if the internal steel wire rope has defects such as warping, breaking, misalignment, and thinning, it cannot be recognized by the naked eye, which affects the safety of the elevator. If the internal wire rope has potential defects at the time of leaving the factory, it is easy to scratch the surface rubber material, which is more likely to cause an accident. Therefore, the damage detection of the composite steel belt plays an important role in the safe operation of the elevator [1]. The rope in the composite steel belt belongs to ferromagnetic component, electromagnetic detection methods is ideal for its non-destructive testing [2]. In addition, the electromagnetic detection method has also been used for fine steel wire rope detection and achieved a good detection effect [3]. The wire ropes inside the composite steel belt are just fine steel wire ropes. Electromagnetic finite element simulation analysis (FEA) can provide magnetic field status reference for electromagnetic detection of wire rope [4]. The application of some magnetic dipole model analysis and related algorithms in electromagnetic detection also provides relevant references for the detection of wire rope defects[5,6]. II. Simulation and Excitation Structure Design The schematic diagram of the common composite steel strip structure is shown in Fig. 1(a), and the excitation structure is established as shown in Fig. 1(b). By selecting the appropriate size of permanent magnet and yoke, the wire ropes in the composite steel belt are excited to near saturation. In the simulation, three defects appear on the first, fifth and ninth wire ropes at the same time. Extract the radial magnetic flux leakage directly above and below each wire rope and above and below both sides of the 1st and 10th wire ropes, as shown in Fig. 1(c) and Fig. 1(d). It can be seen that on the defective wire ropes, the radial magnetic flux leakage is large, and on the wire rope without defects, the magnetic flux leakage is very small. Therefore, magnetic detection sensors (such as hall, anisotropic magneto-resistive, giant magneto-resistive, fluxgate, tunnel magneto-resistive, etc.) can be arranged above and below each wire for picking up the magnetic flux leakage signal, thereby detecting the defect. III. Experimental and Results Since the diameter of the wire rope and the distance between the ropes inside the composite steel belt is small. The hall element having a small volume and high sensitivity is selected as the detecting sensor. The halls are placed above and below each wire rope. For the signal processing, the hall output signals above and below each wire are first summed up. Then the noise and interference signals are filtered out by a bandpass filter. Subsequent use of a comparator to determine the defect. Fig.2a) shows a photograph of a steel belt with three defects, each of which is located on a wire rope inside. Fig.2b) shows the design of the steel wire rope detection device inside the composite steel strip and the detection result when the second defect is detected.

**References:**

[1] H.M. Lei, G.Y. Tian, “Broken wire detection in coated steel belts using the magnetic flux leakage method,” Insight, vol. 55, no. 3, pp.126-31, 2013. [2] H. R. Weischedel, R. P. Ramsey, “Electromagnetic testing, a reliable method for the inspection of wire ropes in service,” NDT&E Int., vol. 22, no. 3, pp.155-161, 1989. [3] X. L. Yan, D. L. Zhang, and S. M. Pan, “Online nondestructive testing for fine steel wire rope in electromagnetic interference environment”, NDT E Int., no. 92, pp. 75–81, 2017. [4] R. H. Priewald, C. Magele, and P. D. Ledger, et al. “Fast magnetic flux leakage signal inversion for the reconstruction of arbitrary defect profiles in steel using finite elements”. IEEE Trans. Magn., vol. 9, no. 1, pp. 506-516, 2013. [5] Li E, Kang Y, Tang J. et al. “Analysis on Spatial Spectrum of Magnetic Flux Leakage Using Fourier Transform”. IEEE Trans. Magn., vol. 54, no. 8, pp. 6201810, 2018. [6] Hosseingholizadeh S, Filleter T, Sinclair A. “Evaluation of a Magnetic Dipole Model in a DC Magnetic Flux Leakage System”. IEEE Trans. Magn., vol. 55, no. 4, pp. 6200407, 2019.

**Images:**
![](https://assets.underline.io/uploads/markdown_image/1/image/71c400da15890673ef973c968b06563d.jpg)

![](https://assets.underline.io/uploads/markdown_image/1/image/245708bac6cfce5ff30346c106e13afb.jpg)

technical paper

INTERMAG 2021 Welcome Video




<figure class="video_container">
 <iframe src="https://screencast-o-matic.com/player/crflqFVnUpZ?v=6&ff=1&title=0&controls=1" width=640 height=360 frameborder="0" allowfullscreen="true"> </iframe>
</figure>

Want to buy a ticket?

Register for INTERMAG 2021 here

[![](https://assets.underline.io/uploads/markdown_image/1/image/17ce76e7960db633258024eef8d6da7f.png)](https://intermag.org/register)

Got your ticket, but still can’t access the event?

Contact us and our team will look into it.

Since its early days, magnetic force microscopy (MFM) has become a truly widespread and commonly used characterization technique that has been utilised in a variety of fundamental and applied research and in industrial applications. In this work, we review the current state-of-the-art, analyse the challenges and outline the future of this fascinating field [1]. In comparison to other magnetic imaging techniques, MFM presents some advantages: high spatial resolution, down to 10nm; ability to work in different environments as vacuum, air or liquids [2] (despite the technical difficulties that are solved, MFM in liquids facilitates the study of biomagnetic materials) and under applied magnetic fields [3] (to study the magnetization reversal process of thin films, nanoparticles and nanostructures). Additionally, MFM exhibits high versatility and simplicity in operation. Advanced operation modes based on Variable Field MFM have proven to be very useful to visualize the magnetization reversal process [4] in one dimensional nanostructures (Figure 1). Isolated multisegmented nanowires (120nm in diameter) formed by segments of FeCo with variable length (increasing from 250nm at the left edge to 400nm the right edge) separated by Cu segments of 30nm have been characterized. The reversal process propagates always unidirectionally (ratched effect) irrespectively of the external field direction, due to the broken symmetry induced by the increasing length of the magnetic segments. Moreover, MFM studies allow us to determine the pinning centers (associated to Cu layers) that may vary from scan to scan. The so called 3D MFM imaging is used is these experiments to obtain a non-standard image where the slow scan corresponds to a continuous variation of the external magnetic field. Some emerging aspects of MFM imaging are also tackled in this work. It is worth mentioning the challenging quantitative and accurate interpretation of the MFM images [5], the probe-engineering alternatives [6] (including the analysis of the active role of the probe what could be used to gain information about the sample stray field with ultra-high resolution) or the MFM experiments on complex magnetic configurations as the skyrmionic states [7,8]. Variable Field MFM and customized MFM probes [6] (growth by Focused Electron Beam Induced Deposition onto AFM probes) have been used for studying skyrmionic states. Figure 2 shows that permalloy hemispherical nanodots with a diameter of 70 nm and height of 30 nm (prepared by hole mask colloidal lithography) are able to host half-hedgehog spin textures with non-zero topological charge. Notice that they are observed at room temperature, in absence of DMI interaction and they can be further stabilized by the magnetic field arising from the Magnetic Force Microscopy probe. The movement of the structure core depends on its chirality and it is controlled by the tip stray field. Micromagnetic simulations have been used to determine the low energy magnetic configuration compatible with the MFM results. Future perspectives of MFM imaging as the characterization of 2D materials and devices for spintronic or straintronic are also address in this work; namely, the in situ combination of magnetic imaging with magnetoelectric, thermoelectric or thermomagnetic characterization.

**References:**

[1] O. Kazakova et al., J. Appl. Phys. 125, 060901 (2019) [2] P. Ares et al., Small, 11, 4731-4736 (2015) [3] E. Berganza et al., Sci. Rep. 7,11576 (2017) [4] C. Bran et al., Acs. Nano. 12, 5932-5939 (2018) , [5] D. Martínez–Martín et al., Phys. Rev. Lett. 105, 257203 (2010) [6] M. Jaafar, et al., Nanoscale 12 , 10090-10097 (2020) [7] M. Baćani et al., Sci Rep 9, 3114 (2019). [8] E. Berganza et al., Nanoscale,12, 18646-18653 (2020)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/975dd1aa3a5f2f1536778690c012b565.jpg)

Fig1: 3D MFM images corresponding to four branches of two pseudo-hysteresis loops. The MFM tip moves continuously along the NW axis (fast scan) while the external magnetic field sweeps (slow scan) from negative to positive fields in (a) and (c) and vice versa in (b) and (d) .

![](https://assets.underline.io/uploads/markdown_image/1/image/69d7e0603796ef2f33a8128bdd729206.jpg)
Fig 2. Sequence of MFM images corresponding to Py hemispherical-shaped nanodots. The images are obtained at different external magnetic fields applied along the X axis. The OOMMF simulations calculated for different in-plane magnetic fields reproduce the parallel to the magnetic field movement of the core, in good agreement with the MFM experiments.

Progress in Magnetic Force Microscopy



Since the 80’s, when Brillouin light scattering emerged as a powerful tool for investigating magnetization dynamics in thin films and multilayers, it developed into a versatile microscopic probe for studying collective spin excitations. Following a short introduction on studies of millimeter-sized films, we will give examples how to investigate individual magnetic structures down to tens of nanometers in dimension. We will introduce the concepts of time- and phase-resolved Brillouin light scattering which give full access to the spatio-temporal evolution of the optically accessible spin-wave spectrum. During our talk, we will provide hands-on demonstrations how to drive spin waves via spin currents and microwave excitations in magnetic nanostructures using the build in dc/ac probe station in our laboratory and show the capabilities of Brillouin light scattering for quantifying spin-wave phenomena. Furthermore, we will highlight similarities and differences to other optical scanning probe techniques such as time-resolved magneto-optical Kerr microscopy and optically detected magnetic resonance based on vacancy centers. We will outline how those techniques can potentially be combined with Brillouin light scattering to access complementary information.
