Knowledge graphs, or node-edge graphs representing entities and relationships are fundamental to a wide variety of cutting-edge Natural Language Processing (NLP) tasks including search, question-answering, salience determination, slot-filling, and event schema induction. Such tasks enable advanced analytics that allow users to derive new, meaningful insights about their data and are particularly useful in the realm of Big Data. Google’s Knowledge Graph, for example, forms the backbone of its search engine, enabling Google to make more intelligent inferences about results relevant to user queries. Knowledge graphs and their associated NLP tasks are widely applicable to large Navy text corpora including Navy missile standards documents, instrument logs, and cybersecurity and safety policy documents.

The goal of this project is to build a Natural Language Processing (NLP) pipeline capable of ingesting a corpus of documents and automatically creating a Knowledge Graph containing the entities and relationships in the corpus. We are constructing an end-to-end pipeline composed of six modules: Coreference Resolution, Open Information Extraction, Canonicalization, Entity Linking, a Neo4j Graph Database, and a Graphical User Interface (GUI).

We first perform Coreference Resolution (AllenNLP) on the corpus to create a single term for all expressions that refer to the same entity. We then extract all subject-predicate-object triplets using Open Information Extraction models by Stanford, AllenNLP, and the University of Washington and IIT Delhi; currently the user can choose a single model or a combination of models. Next we map each name to a canonical form, by clustering entities via cosine similarity, Jaccard similarity, or inverse document frequency. We then link our entities to existing entities with the same names in a pre-constructed knowledge base (KB), in effect ingesting all knowledge contained in the KB. Finally, we load the processed subject-predicate-object triplets into a Neo4j graph database, accessible to users via our GUI.
The GUI provides an interface through which users can input text data, either by uploading files or typing raw text, choose pipeline modules to include and models and thresholds to use, query the database, run advanced analytics, produce interactive graph visualizations, and save data and visualizations.

Through the aforementioned six modules, our project is an end-to-end pipeline of state-of-the-art methods for converting unstructured text data into a structured Knowledge Graph.
