Radio Modulation classification (RMC) is an important front-end step in a number of applications such as Signals Intelligence, spectrum monitoring, link adaptation, dynamic spectrum access, cognitive radio and 4G/5G cellular standards. We report on an RMC method which uses a novel multi-channel Time-Series Imaging input to a hybrid Residual CNN-BiLSTM Deep Neural Network. Training and testing on the RadioML 2018.01A 24-class dataset shows a peak accuracy of 96% at the highest SNRs and improvement at lower SNRs using the hybrid architecture. A new amateur radio satellite downlink collection effort for a modulation classification dataset with naturally varying SNR, Doppler shift and various bit rates will also be discussed.
