In recent years, deep neural networks have achieved
state-of-the-art performance in a variety of recognition and
segmentation tasks in medical imaging including brain tumor
segmentation. We investigate that segmenting a brain tumor is
facing to the imbalanced data problem where the number of pixels
belonging to the background class (non tumor pixel) is much
larger than the number of pixels belonging to the foreground
class (tumor pixel). To address this problem, we propose a multitask
network which is formed as a cascaded structure. Our model
consists of two targets, i.e., (i) effectively differentiate the brain
tumor regions and (ii) estimate the brain tumor mask. The first
objective is performed by our proposed contextual brain tumor
detection network, which plays a role of an attention gate and
focuses on the region around brain tumor only while ignoring the
far neighbor background which is less correlated to the tumor.
Different from other existing object detection networks which
process every pixel, our contextual brain tumor detection network
only processes contextual regions around ground-truth instances
and this strategy aims at producing meaningful regions proposals.
The second objective is built upon a 3D atrous residual network
and under an encode-decode network in order to effectively segment
both large and small objects (brain tumor). Our 3D atrous
residual network is designed with a skip connection to enables the
gradient from the deep layers to be directly propagated to shallow
layers, thus, features of different depths are preserved and used
for refining each other. In order to incorporate larger contextual
information from volume MRI data, our network utilizes the
3D atrous convolution with various kernel sizes, which enlarges
the receptive field of filters. Our proposed network has been
evaluated on various datasets including BRATS2015, BRATS2017
and BRATS2018 datasets with both validation set and testing
set. Our performance has been benchmarked by both regionbased
metrics and surface-based metrics. We also have conducted
comparisons against state-of-the-art approaches

ICPR 2020

A Multi-task Contextual Atrous Residual Network for Brain Tumor Detection &amp; Segmentation

brain tumor

imbalanced data

medical imaging

segmentation

deep learning

detection

ICPR 2020 is the premier international conference on Pattern Recognition, gathering leading researchers from around the world to present their latest achievements in Pattern Analysis and Recognition, applied Artificial Intelligence and Machine Learning. The topic of the year is " Putting Artificial intelligence to work on Patterns".
For the first time, ICPR has employed a two-round review process similar to journal submissions, with new papers allowed to be submitted in either the first or second round and papers submitted in the first round and not accepted allowed to be revised and re-submitted for second round review.

In this edition of the **ICPR 2020** Conference, there are 1407 Oral/Poster presentations organized in five Tracks:
- Artificial Intelligence, Machine Learning for Pattern Analysis;
- Biometrics, Human Analysis and Behavior Understanding; Computer Vision, Robotics and Intelligent Systems;
- Document and Media Analysis; and
- Image and Signal Processing.

The **ICPR 2020** Main Conference program also includes 7 Keynotes from prominent world-renowned scientists, 8 Tutorials, 28 Demos, 8 Challenges, 2 Panels, as well as an Industry/Sponsor Exhibition. In addition, 41 Workshops on a range of important current and emerging research topics complete the ICPR 2020 program.


A Multi-task Contextual Atrous Residual Network for Brain Tumor Detection & Segmentation

poster
